Dräger X-dock User Manual

Dräger X-dock
Frequently Asked Questions
COSTS Why do I save costs when using Dräger X-dock?
The daily test is important – but it costs time and money. Especially the gas
consumption plays an important part. The often used flow of 500ml/min and
test periods of e.g. 60 seconds result in a high gas consumption. For instance,
1000 tests carried out using these parameters would result in a consumption of
500 liters of gas!
The Dräger X-dock has got typical opening times for the gas supply valves with
a fast gas application test of 10 seconds or even less for gases such as CH
4
, O
2
,
CO and H
2
S. In addition, it uses a flow of 300ml/min. With these parameters
a consumption of 50 liters with 1000 tests is achieved which means saving 90%
of gas compared to the volumes mentioned above.
X-dock does not waste gas: When the value is reached the valves are closed
immediately.
HOME
 
9094227_X-dock_FAQs_210x297_ENGL_5 20.11.13 12:10 Seite 3

Dräger X-dock Specifications

General

Power Supply	100 – 240 VAC, 50 – 60 Hz
Humidity	10 to 95 % RH, non-condensing
Data Storage	Internal memory for device data, calibration data, and test results
Interface	USB, Ethernet
Device Type	Automated test and calibration station
Calibration	Automatic calibration
Bump Test	Automatic bump test
Supported Gases	Depends on the gas detector being tested (e.g., H2S, CO, O2, LEL)
Compatibility	Compatible with Dräger portable gas detectors
