AT+TRIG=0,100, 2 (set DI2 port to trigger on low level, valid signal is 100ms)
AT+TRIG=1,100, 2 (set DI2 port to trigger on high level, valid signal is 100ms )
AT+SETCNT=1,60 (Set COUNT1 value to 60)
AT+SETCNT=2,60 (Set COUNT2 value to 60)
For both LT22222-L & LT33222-L:
AT+CLRCOUNT clear all countings
AT+COUTIME=60 Set save time to 60 seconds. Device will save the counting result in internal
flash every 60 seconds. (min value: 30)
3.3.3 AT+MOD=3, Single DI Counting + 2 x ACI
LT33222-L: This mode the DI3 is used as a counting pin.
LT22222-L: This mode the DI1 is used as a counting pin.
Size(bytes)
4
2
2
1
1
1
Value
COUNT1
ACI1
Current
ACI2
Current
DIDORO*
Reserve
MOD
DIDORO is a combination for RO1, RO2, DI3, DI2, DI1, DO3, DO2 and DO1. Totally 1bytes as below
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
RO1
RO2
FIRST
Reserve
Reserve
DO3
DO2
DO1
 RO is for relay. ROx=1 : close，ROx=0 always open.
 FIRST: Indicate this is the first packet after join network.
 DO is for reverse digital output. DOx=1: output low, DOx=0: high or float.
Note: DO3 is not valid for LT-22222-L.
To use counting mode, please run:
AT+MOD=3
ATZ
Other AT Commands for counting are similar to MOD2 Counting Command.
