- 9 -
OPERATION & USE
CHANGING SPEEDS
1. Turn the main power switch off and
disconnect from the power supply.
2. Remove the front cover.
3. Refer to Fig.8. and check which pulley
steps to use for the desired speed
and adjust as required.
4. Change the belt on the motor pulley
or drive wheel will allow you to move
it from a larger diameter step to a
smaller step.
5. Replace the front cover.
ON/OFF SWITCH
When key is in the off/locked position, it
will prevent unauthorized operation of
the bandsaw (Fig.6).
The bandsaw is fitted with a no volt
switch. In the event of a power supply
failure the bandsaw will have to be
manually re-started (Fig.7).
Fig.6.
Fig.7.
DRIVE WHEEL
MOTOR PULLEY
Fig.8.
