Draper FlexShade - Mounting Headbox with Brackets

Side
Channel
Side
Channel
HEM
BAR
Section 3.3 - Attaching Side Channels to Mounted Headbox
5.
Re-attach Side
Channel Covers,
replacing the
screws removed in
Sec. 3.1, Step 1.
1.
Insert Side
Channel Guide
into Side
Channels.
3.
Attach Side
Channel to
mounting surface using
appropriate fasteners.
4.
Repeat for the other
Side Channel.
2.
Insert Hem
Bar into Side
Channel.
Please Note: Failure
to use provided
fasteners to re-
attach
Side Channel
covers may result
in product failure in
high wind.
IMPORTANT: Side Channels
must be installed parallel,
plumb and square, with a
tolerance of +/- 1/8 " (3mm) .
Section 3 - Installing Side Channels Option
Section 3.1 - Preparation
1. Use 3 mm Hex Wrench to remove Screws from Side Channels and
Side Channel Covers (Fig. 4-A) .
Please Note: Do NOT remove the Bottom Caps from Side Channels.
2. Drill Side Channels at desired mounting points.
3. Mark wall or jamb and drill small pilot holes in mounting surface (Fig. 4-B) .
Please Note: Recommended attachment of Side Channel to structure is
minimum of every 24" (61cm) .
Jamb Mount
Pilot Hole
Wall Mount
Pilot Hole
Side
Channel
2
SIDE CHANNEL COVER
1
Figure 4-A
Figure 4-B
WALL
WALL
Endcap
Endcap
Side
Channel
Side
Channel
WALL
WALL
Side
Channel
Guide
Side Channel
Guide Properly
Engaged
in Headbox
WALL
WALL
Endcap
Endcap
Side
Channel
Side
Channel
WALL
WALL
Side
Channel
Guide
Side Channel
Guide Properly
Engaged
in Headbox
Wall Mounting
Jamb Mounting
Wall Mounting
Jamb Mounting
page 4 of 12
Exterior Motorized FlexShade
®
