Section 10 - Cable Exit
The Exterior Motorized FlexShade
®
can be ordered with a cable exit pre-drilled in the top or back of the Headbox. If no cable exit is specified,
the cable is routed down and out the fabric opening under the motor.
Please Note: Right hand motor is shown.
(19mm)
(17mm)
Cable Exit:
SIDE
TOP
BACK
(13mm)
ENDCAP
F
R
O
N
T
F
R
O
N
T
(9.5mm)
(13mm)
(22mm)
1
(25mm)
Cable Exit:
TOP
TOP
BACK
(13mm)
ENDCAP
F
R
O
N
T
F
R
O
N
T
(9.5mm)
(13mm)
1
(30mm)
Cable Exit:
BACK
TOP
BACK
(13mm)
ENDCAP
F
R
O
N
T
F
R
O
N
T
F
R
O
N
T
Figure 6-A Figure 6-B
Figure 6-C
Section 9 - Anti-Insect Brush Seals Option
2.
Install brush
seals on each
Side Channel.
Insect Barrier
Brush Seal
TOP OF
SIDE
CHANNEL
Figure 5
VINYL BULB SEAL
HEM BAR LINER
(17mm)
HEM BAR
LINER
Section 8 - Hem Bar Liner Options
Please Note: Liner is factory installed
(if ordered)
.
1.
Remove double-sided
tape and apply to Side
Channels.
(Fig. 5)
.
page 8 of 12
Exterior Motorized FlexShade
®
