Section 11 - Assembled Dimensions
(Front View)
Side Cable Option
Side Channel Option
Shade Width
Shade
Height
Hem Bar Length
2 "
(57mm)
1 "
(30mm)
Fabric Width
"(6mm)
Both
Sides
Gap between
Hem Bar &
Side Channel
1 "
(41mm)
1 "
(30mm)
Shade Width
Shade
Height
Side
Channel
Length
Hem Bar Length
Fabric Width
2
"
(57mm)
1 
(41mm)
Side
Channel
Length
Deck Mounted Cable Guide option,
configured for Inside Mount.
For Outside Mount installation,
Cable Guide may be turned 90°.
Wall Mounted
Cable Guide option
page 9 of 12
Exterior Motorized FlexShade
®
