Draper Motorized FlexShade - Coupler Dimensions

11
Intermediate Panel
Intermediate Panel
1
MOTOR
ENDCAP
Motor Shade Panel
IDLER
ENDCAP
Intermediate Panel
Idler Shade Panel
* This dimension may be larger, depending on motor selection. Contact Draper
®
for motor verification.
COUPLER ASSEMBLIES
1
* *
Section 10 - Coupler Dimensions
Motorized FlexShade
®
Idler Endcap Mounting Dimensions
FlexShade
®
Coupler
Mounting Dimensions
4 "
(114mm)
3 "
(83mm)
1 "
(35mm)
1"
(25mm)
2 "
(57mm)
2 "
(57mm)
"
(17mm )
1"
(25mm)
4 "
(114mm)
2"
73mm
4"
117mm
"
16mm
4
"
117mm
page 12 of 12
Motorized FlexShade
®
(Coupled)
