OPTIONAL ACCESSORIES
- 14 -
PART NO.: ABTS1
STOCK NO.: 65840
DESCRIPTION: TABLE SAW STAND FOR BTS251
PART NO.: ABTS2
STOCK NO.: 65841
DESCRIPTION: EXTENSION WING (1) FOR BTS251
BLADES:
Key. Diameter Stock. Part No. of Bore Reducing Type Finish
No. No. No. Teeth mm Bushes
Supplied
1 250mm (10") 27852 CSB250 24 30 20 + 25mm Rip & Cross Coarse
+ 5/8" Cut
2 250mm (10") 30732 CSB250E 40 30 5/8" Cross Cut Medium
3 250mm (10") 27854 CSB250 40 30 20 + 25mm Cross Cut Medium
+ 5/8"
4 250mm (10") 27855 CSB250 60 30 20 + 25mm Cross Cut Fine
*
5 250mm (10") 27856 CSB250 80 30 20 + 25mm Cross Cut Fine
+ 5/8
* Use in conjunction with reducing bush Stock No.25538.
OPTIONAL ACCESSORY ASSEMBLY
ABTS1 See assembly instruction sheet enclosed with stand.
65840
ABTS2 The extension wing can be set to fit on either side of the table, according
65841 to preference.
For example, fitting on the right side of the work table.With the scale end
nearest, loosen the extension wing's wing bolts, set both the metal rods with
the exposed section out of the left side. Tighten the wing bolts. Loosen the
wing bolts on the table and slide the extension into position, with no gap
between the table and the wing, lock all the wing bolts securely.
