Section 13 - Wiring Diagrams: 220V Standard Motor
Please Note: Do not wire motors in parallel.
* These wiring diagrams
are for Ultimate Access
screens with motor on
audience left
(standard)
, and
fabric unrolling from the
back of the roller
(standard)
.
Neutral
L1
220V,
Dashed wiring
by installer.
Control
switch
Internal Screen Wiring
Blue-220V (Common)
Brown-220V (Up)
Black-220V (Down)
Green/Yellow (Motor Ground
CE Approved
Dashed wiring by electrician
Low-voltage wiring by others
3 Button Wall Switch
DOWN - Black
COM - White
UP - Red
To
230 VAC
Line
White-Common to screen & 230V AC Neutral
Red-to screen (directional)
Brown-to screen (directional)
Yellow-to 230V AC-Hot
Black-to 230V AC-Hot
Green/Yellow (Ground)
Blue (Common)
Brown (Up)
Black (Down)
Internal Screen Wiring
Electrically Straight
Data Cable to more
LVC-IV modules.*
*A maximum of six (6)
LVC-IV modules can be
linked together.
N
L1
GND
Location of key
operated 0n-off
switch if furnished.
IR Eye Input
Low-Voltage Trigger
4-28 VDC
RS232/485
Inputs/Outputs
Receiver
Button
Wall Swit
Green/Yellow
(Motor Ground)
FUSE - 3.15 AMP
250 VAC 5x20mm
External LVC-IV - Single or Multiple Projection Screen Wiring Diagram
FUSE - 3.15 AMP
250 VAC 5x20mm
Receiver
Button
3 Button Wall Switch
DOWN - Black
COM - White
UP - Red
Electrically Straight
Data Cable to more
LVC-IV modules.*
*A maximum of six (6)
LVC-IV modules can be
linked together.
IR Eye Input
Low-Voltage
Trigger
4-28 VDC
RS232/485
Inputs/Outputs
Dashed wiring by electrician
Factory wiring
Low-voltage wiring by others
To
230 VAC
Line
Green/Yellow (Ground)
Blue (Common)
Brown (Up)
Black (Down)
Green/Yellow
(Motor Ground)
Location of key
operated on-off
switch if furnished.
Black-to 230V AC-Hot
Red-to screen (directional)
Brown-to screen (directional)
Yellow-to 230V AC-Hot
White -Common to screen & 230V AC Neutral
W
all Switch
INTERNAL SCREEN WIRING
GND
L1
N
Internal LVC-IV - Single or Multiple Projection Screen Wiring Diagram
Internal LVC-IV - Single or Multiple Projection Screen Wiring Diagram
External LVC-IV - Single or Multiple Projection Screen Wiring Diagram
page 7 of 7
Ultimate Access E and V 220V
