Descriptions of Components
LED Status Explanation
Blinking VigorAP is ready and can work normally. Blue LED
Off VigorAP is not ready or fails.
Purple LED On Power adapter is plugged in and VigorAP is
initializing
Orange LED Blinking The firmware upgrade is in process.
Off Off VigorAP is turned off or not functioning.
Interface
Explanation
Ethernet Port Connects to LAN or router.
Supports PoE power & Gigabit (1000BaseT).
Power Jack (DC IN) Connecter for a power adapter.
Hole
Explanation
Factory Reset Restores the unit back to factory default settings.
To use, insert a small item such as an unbent
paperclip into the hole. You will feel the button
inside depress gently. Hold it for 10 seconds.
The VigorAP will restart with the factory default
configuration and the LED will blink blue.
Note: For the sake of security, make the accessory kit away from children.
LED
Factory
Reset
Ethernet Port
Power Jack (DC IN)
