- 11 -
OKC 100 NTR/HV, OKC 125 NTR/HV, OKC 160 NTR/HV
Figure 6
*Height from the upper heater's edge to the end of the water inlet and outlet tubes.
Table 4
neck #1 3/4" outer
neck #2 3/4" outer
neck #3
3/4" outer
neck #4
3/4" outer
neck #5
3/4" outer
neck #6 1/2" inner
TYPE
OKC 100 NTR/HV
OKC 125 NTR/HV
OKC 160 NTR/HV
A
902
1067
1092
B*
893
1058
1079
C
144
144
146
D
524
524
584
E
165
165
165
F
119
119
119
G
182
182
182
