- 18 -
3 OPERATION OF THERMOSTAT
3.1 SERVICING
3.1.1 OPERATING DEVICES OF THE HEATER
Electrical installation cover for heaters OKCEV 200, OKCV 200
Thermostat knob Electric circuit closing indicator lamp Tipping plastic guard
Figure 11
Electrical installation covers for heaters OKCEV 100, OKCEV 125, OKCEV 160, OKCV 125, OKCV 160
Thermostat knob Electric circuit closing indicator lamp
Figure 12
Thermostat and no other part of the control panel is not a bearing part which can be
used for any handling with the heater.
