Dražice OKCEV 100 - Temperature Setting

- 19 -
3.1.2 TEMPERATURE SETTING
Water temperature is set by turning the thermostat knob. The desired symbol is adjusted against the solid
mark on the control panel.
Figure 13
Figure 14
Adjusting the thermostat knob to the left backstop does not mean permanent shutoff
of the heating element. When the heater is in use without blocking the daily rat
e, we do not
recommend the temperature to be set above 55°C. Select the "ECO“ symbol
as the maximum.
Lower limit of technical
scope (around 5°C)
Temperature to prevent
freezing (around 8°C)
Fixed mark on control
panel
Upper limit of technical
scope (around 80°C)
Optimum temperature
(around 55°C)
Lower limit of technical
scope (around 5°C)
Fixed point on control panel
Temperature to prevent
freezing (around 8°C)
Upper limit of technical
scope (around 74°C)
Optimum temperature
(around 55°C)
