4. As shown below, balance glider on fingertips or balancing stand at CG location marks under wing. Add or
remove balance weight until glider balances in level position. You may need a few smaller pieces of weight
to get the balance just right.
5. Secure battery with hot glue and attach required weight using a bit of painter's tape (this can be removed
during fine-tuning of CG position). If desired, secure receiver in position with a bit of double-sided tape.
CONTROL SURFACE DEFLECTIONS
The control surface deflections in the table below provide the Libelle with active response to control inputs. You
can set separate Low and High rates using the "Dual Rate" menu and toggle switches on your programmable
radio. Note: Deflections can be adjusted to suit one's own flying style.
►HOT TIP: Stick a piece of painter's tape to the tail
boom, just behind the control surface for setting
deflections. As shown, mark desired deflections on tape
and adjust transmitter rates accordingly until proper
deflection is achieved.
