Routine Maintenance
3. Clean the mop pad with water only and leave it to air dry before
re-installing.
4. If the water flows too slowly or the outflow is not well-distributed,
please clean the air hole on the cover of the water tank.
Remove the pad from the mopping module before cleaning it. Make sure dirty water
does not flow back into the water outlet to avoid clogging.
Note:
Clean the Main Brush
1. Press the brush guard clips inwards to remove the brush guard
and lift the brush out of the robot.
2. Pull out the brush covers as shown in the diagram. Use the
included cleaning tool to remove any hairs tangled in the brush.
Note: Do not pull out the hair tangled in the main brush too vigorously. Doing so may
damage the brush.
12
6
111
57
210
48
39
24 hrs
Clean the Side Brush
Clean the Main Wheel / Universal Wheel
Routine Maintenance
Note: Use a tool such as a small screwdriver to separate the axle and tire of the universal
wheel.
To Next Page
