Factory Parts Information
Contact Support@DreamLine.com for Part replacement, installation assistance or additional information.
Complete Warranty information is available on DreamLine.com.
ASCEND Shower Door Manual Ver 1 022021 26
© 2021 DreamLine® All Rights Reserved
ITEM # FACTORY PART NUMBER ITEM DESCRIPTION QTY
01 042580X1-1828 Wall Profile 1
02 07020241 Wall Bracket 1
03 091107 ST4.0 x 40mm Screw 7
04 07552148 Wall Anchor 7
06 0702X243 Pivot 2
07 042590X1-1828 Glass Profile 1
08 07020242 Glass Bracket 1
09 095214 M6 x 16mm Screw 4
10 063067000-1828 Vertical Vinyl Seal 1
11 095212 M5 x 10mm Screw 1
12 096016 Lock Washer 1
13 091101 ST4.0 x 10mm Screw 7
14 0755X011 Washer/Screw/Cap 7
15 0722X095 Handle 1
16 042440X1-1828 Strike Side Wall Profile 1
17 042430X1-1828 Strike Side Glass Profile 1
18 061071100-1828 Strike Vinyl 1
19 063006100-0857 Bottom Sweep 1
BOLD digit indicates finish: 1 = Chrome; 4= Brushed Nickel; 06=ORB: 09=Sa�n Black
BOLD digit indicates finish color:
1 or 8 = Polished SS
4 or 5 or 7 = Brushed SS
6 = Oil Rubbed Bronze
9 = Sa�n Black
ASCEND {SDAD27D720}
FACTORY PARTS INFORMATION
