Installation Steps
Tools Needed
Parts Needed
ASCEND Shower Door Manual Ver 1 022021 8
© 2021 DreamLine® All Rights Reserved
01
x1
Place the Wall Profile (#01) on the hinge side of the opening. Be sure to account for the
2-3/8” overall footprint of the shower door. Fig 1a Use a level to plumb the Wall Profile.
Mark the position of the Wall Profile as well as the holes for drilling. Figs 1b and 1c
NOTE
2-3/8”
Wall Profile to
be installed
Fig 1a
Fig 1b
Fig 1c
1
