Tools Needed
ASCEND Shower Door Manual Ver 1 022021 9
© 2021 DreamLine® All Rights Reserved
Fig 2
Using the drilling instructions below, drill holes on the marks just made. Apply a good quality, mildew resistant
silicone to the back of the Wall Profile as well as in the screw holes and place the Wall Profile back on the
marks made on the wall in Step #1. Fig 2
NOTE
NOTE
◾If a stud is present behind the wall:
Drill a Ø3/16”(4mm) hole to the stud, drill an
Ø1/8”(3mm) pilot hole into the stud and use
the designated screw.
OR
◾If no stud is present behind the wall:
Drill a Ø5/16”(7mm) hole and insert a Wall Anchor (#04)
and use the designated screw.
32
1
2
To Next Page
