Tools Needed
Parts Needed
ASCEND Shower Door Manual Ver 1 022021 10
© 2021 DreamLine® All Rights Reserved
Align the Wall Bracket (#2) with the holes in the top of the Wall Profile (#01). Install both with the ST4.0 x
40 mm Screw (#03). Continue to install the Wall Profile (#01) using the ST4.0 x 40 mm screws. Fig 3
Always drill the correct size pilot holes according to the manual, and always
use low torque and steady pressure when installing stainless steel screws.
NOTE
02
x1
01
x1
03
x7
2 3
1
Fig 3
TIP
3
To Next Page
