DREAMS Jay - Assembly Hardware and Tools; Hardware for Bed Frame Assembly; Hardware for Slat and Support Systems

Jay Ottoman Bed - Assembly guide - Page 6
Cross head screwdriverTape measure
Tools required
m x5
b x5 c x5
Bolts (M8x25mm) for fitting
ottoman support bar
Flat washer for M8 bolts
O x1
Q x1
P x1
Spring washer for M8 bolts
Hardware needed for fixing ottoman support bar (O.S.B) to the slat frame
packed in the side rail carton, inside Pack 2 - hardware pack (C
)
Ottoman Support Bar
Fixed retaining bracket
- side rail
Parking bracket - slat frame
Spring Washer for M8 bolt Flat Washer for M8 bolt
h x4
i x8
q x1
Flanged lock-nuts M8
for gas-lift pistons
Nuts for M8 bolts
Tube spanner for M8 nut
n x2
b x16 c x16
k x6
Big Head Bolts (M8x20mm) for
fitting metal plate (R) and
mattress base boards (W&X)
mattress stoppers (T) to
r x8
Metal connection plate for
mattress base boards (W&X)
l x8
Bolts (M8x30mm)
Fitting mattress base boards
to gas-lift mechanisms
Threaded stud (M8x50mm)
Fittings
Please check you have all the fittings listed below with your product:
Hardware needed for fixing side rails to headboard & footboard
Packed in side rail carton, inside Pack 2 - hardware pack (A)
Hardware needed for fixing mattress base board
Packed in mattress base board carton, inside Pack 3B - hardware pack (D)
Spring Washer for M8 bolt
a
Flat Washer for M8 bolt
b c
d x1
Allen Key for M8 bolt
Bolts (M8x25mm)
Fitting side rails (C&D) to
headboard & footboard (A&B)
e
Bolts (M8x50mm)
Fitting Support block (p)
to side rail cross bar (G)
Double & King x28
Super King x30
Double & King x26
Double & King x1
Super King x2
Double & King x1
Super King x2
Double & King x29
Super King x32
p
Support block
for side rail
cross bar (G).
