DREAMS Jay - Attaching the Side Rail Cross Bar

Jay Ottoman Bed - Assembly guide - Page 13
WARNING!HA ZARD- DO NOT REACH INTO THE SPACEBELOW!
WARNING!HAZARD - DO NOT REACH INTOTHE SPACE BELOW!
H
11
12
b
x4
c
x5
d
x1
e
Double & King x1
Super King x2
Double & King x1
Super King x2
p
a
x4
ii) Using four bolt sets (a, b & c) fit the
cross bar (G) to both side rails (C&D).
Tighten 100% using Allen key (d).
Take care not to damage the fabric
when fitting.
i)
Fit the support block (p) in the centre of the
side rail cross bar (G) using a bolt & flat washer
(e & c) (N.B. there are two blocks on the Super
King size). Tighten 100% using Allen key (d).
G
a x2
e
c
c x2
b x2
G
G
Fit the fabric base cover (H) evenly around the inside of the bed
Fit the 'U' shaped side rail cross bar (G).
