Wilson Ottoman Bed - Assembly guide - Page 9
A
A
B
&
A
B
&
B
C
C
C
E
H
C
C
C
Bed Assembly - Use Pack 'B'
Loosely insert two bolt
sets (a, b & c) into each side of the headboard & footboard.
Note: Do not tighten fully but leave 10mm protruding as in the diagram.
10mm
a
b
c
a.
b.
Fit the side rails locating the
brackets behind the flat washers.
ii)
i)
Please do not tighten
any bolts yet.
Make certain the bed is
squared up as in the diagram.
Once all four corners are located tighten
all the bolts using the Allen key (d).
a
b
c
d
Using bolt sets
(a, b & c) fit angle brackets
(E) into the threaded inserts in the corners of
headboard, footboard & each side rail.
iii)
vi
)
iv
)
k
k
2
a x8 b x8
c x8 d x1
a x16 b x16
c x16 d x1
k x4
Fit bolt sets to
Headboard &
Footboard (A&B)
like this
A
B
&
v)
Fit the 'U' shaped cross bar (H) to centre
of
each side rail (C). Line up the ends
of the
bar between the two marked lines
& fix into
the side rails using screws (k).
Note the screws drive straight into the side rail
itself, there are no pilot holes.
.
.
.
3
