Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
Functional Description and Specifications
Model 2050 High Speed Rotary Tool
ON/OFF
BUTTON
SHAFT LOCK
BUTTON
POWER
SUPPLY
DC
SOCKET
DC
JACK
VENTILATION
OPENINGS
COLLET
NUT
Model number 2050
Power Input rating 120V 60Hz
Power Output rating
18V 0.5A
Rated speed n 5,000—22,000 /min
Nut capacity 1/32"—1/8"
FIG. 1
VARIABLE
SPEED DIAL
