11
Disconnect battery pack from tool before making any assembly,
adjustments or changing accessories. Such preventive safety measures
reduce the risk of starting the tool accidentally.
Model number 8220
Voltage rating 10.8V/12V MAX
Rated speed n 5,000 - 35,000/min
Collet capacities 1/32, 1/16", 3/32", 1/8"
Functional Description and Specifications
Model 8220 Cordless Rotary Tool
COLLET
WRENCH
ON/OFF SWITCH
SHAFT LOCK
BUTTON
VARIABLE SPEED
ADJUSTER
VENTILATION
OPENINGS
HANGER
COLLET
NUT
COLLET
SHAFT
Charger 876
Charge Time 1 Hour
Voltage rating 120 V 60 Hz
Battery pack 875, B812-01, B812-02,
and B812-03
Capacity 1.3 Ah, 1.5 Ah, or 2 Ah
BATTERY
RELEASE TABS
BATTERY
PACK
FUEL GAUGE
EZ TWIST™
INTEGRATED
WRENCH/NOSE CAP
