PCU LED
24
The PCU LED (Post Curing Unit LED)
is a light polymerization device for the
curing of components which have been
created by means of 3D printing. The
following device properties are used in
the curing process:
a) LED technology
b) Electronic control
(micro-controller)
c) Logging and monitoring of the
process parameters
d) Simple control concept
e) Process reliability
f) Different curing environments
(air, vacuum, nitrogen)
g) Open system
Device properties:
a) LED technology
The advantages of the LED technol-
ogy are that a permanent light of
one wavelength is emitted. The per-
manently emitted light radiation can
be captured by a standard UV sensor
and thus allows for the measurement
and the observation of the light out-
put in the exposure chamber. Further-
more, LED lamps do not produce any
heat which could cause the material
properties of the plastic component to
be cured to be negatively influenced.
Another advantage of the LED tech-
nology is that the stated operating life
of the LED lamps is approx. 20,000
hours and is accompanied by low
operating and maintenance costs.
b) Electronic control (micro-controller)
The use of a micro-controller allows for
1. Device description
the control and reading of the current,
pressure and temperature sensors.
c) Logging and Monitoring
The information which is recorded by
the current, pressure and temperature
sensors represents the used process
parameters (e.g. light on/off; vacuum
on/off; nitrogen on/off). These process
parameters are recorded, saved and
transferred to a USB storage medium.
This allows for the transparent trace-
ability of the production chain of the
medical device.
d) Simple control concept
The device is operated by the removable
rotary button. The corresponding option
is selected by turning the button. The
selected option is operated by pressing.
Longer pressing opens the parent and
sub-folder menu. Another removable ele-
ment is the handle which is used to open
the lid of the exposure chamber. Both
elements can be cleaned with the appro-
priate cleaning agents after removal.
e) Process safety
To be able to guarantee a high process
liability, the control software is subdi-
vided into two levels. Level 1 is accessi-
ble to the user and process owner. Level
2 is only accessible to the process owner.
In level 1 only a predefined process can
be selected. In level 2, for example, a
process can be defined and an option
can be switched on and/or off.
f) Curing environment
The components to be cured can be
