Blue Tooth Setup
If you have ordered a Bluetooth equipped CarDAQ Plus 2
®
, you will have an antenna and
Bluetooth USB dongle included. Drew Technologies supports Bluetooth Diagnostics, but will
not provide support for module programming done via Bluetooth. To setup your CarDAQ Plus
2
®
to communicate with your PC, you will need to perform several steps listed below:
1. Thread the antenna onto the gold stud labeled “Wireless” on the back faceplate of the
CarDAQ Plus 2
®
between the “Aux” and “Vehicle Cable” ports.
2. Insert the USB Bluetooth Dongle into a known good USB port on your PC and allow
Windows to install the drivers for it.
3. Plug the vehicle cable into your CarDAQ Plus 2 and a vehicle.
4. The Power LED and Car LED will be lit up Solid green. The Wireless LED is will be
flashing a different shade of green.
5. For Windows 10, skip to step 10. Windows 7, Once the driver installation reports
complete, Right click the BlueTooth icon in your system tray in the lower right corner.
6. Click Add a device.
7. Click “CarDAQ-Plus2-######” where the ##### corresponds to the serial number on the
bottom of the case.
8. Click next.
9. Enter “2534” if prompted for the PIN code.
10. Windows 10. Once the driver installation reports complete, Right click the BlueTooth
icon in your system tray in the lower right corner.
11. Click Add a Bluetooth Device.
12. Wait until you see “CarDAQ-Plus2-######” where ##### corresponds to the serial
number on the bottom of the case.
13. Click Pair.
14. Enter “2534” if prompted for a PIN code.
PRODUCT SPECIFICATIONS
Protocols Supported:
• CAN Bus (capable of ISO 15765, GMLAN, J1939, and ISO14229)
• 2nd CAN (Dual or Single Wire)
• Ford SCP (J1850PWM)
• GM Class2 (J1850VPW)
• KWP2000 (ISO9141/14230)
• Chrysler SCI (J2610)
•
Compliant to SAE J2534 (Feb 2002) and SAE J2534-1(Dec 2004)
• Compliant to ISO 22900-1 MVCI physical layer
• Programming voltage on J1962 pin 6, 9, 11, 12, 13, 14, or Aux
• Ground pin 9
