System messages
The Revolution control system constantly monitors internal operating conditions. If the system detects a problem, it will
produce an error (“ER”) message. If the display shows an ER message, first unplug the unit and then plug it back in. This
will usually reset the electronics, and the unit will begin operating normally. If the error message reappears, refer to the
explanation and solution shown below. If this still does not fix the problem, contact your local authorized service center or
call the Dri-Eaz Service Department at 800-932-3030.
NOTE: The message “POWER FAILURE” is not a system error. When this message is displayed, it indicates that
power to unit was interrupted and then restored. To clear the message, press the MENU SELECTION key.
CONTROL PANEL
MESSAGE
EXPLANATION AND SOLUTION
ER1 CONTACT SERVICE
CENTER
Voltage error. Confirm that unit is connected to a suitable AC power supply and that the
circuit is not overloaded. If supply is correct, the electronic control panel may require
replacement. If error persists, contact service.
ER2 CONTACT SERVICE
CENTER
Control panel error. The electronic control panel may require replacement. If error per-
sists, contact service.
ER3 CONTACT SERVICE
CENTER
Unit in defrost too long. Check defrost sensor cable for proper connection. If error per-
sists, sensor assembly may require replacement. Contact service.
ER4 √ DEFROST SENSOR
CONNECT
– alternate message –
ER4 √ OUTLET SENSOR
CONNECT
Sensor error. Check defrost sensor cable for proper connection. If error persists, sensor
assembly may require replacement. Contact service.
ER5 √ SENSOR
CONNECTION ON BD
Check inlet Temp/RH sensor for proper connection. If error persists, contact service.
ER6 CONTACT
SERVICE CENTER
High voltage error. The high voltage board may require replacement. If error persists,
contact service.
ER7 INVALID
MODEL SETTING
Control board DIP switch settings or firmware version may be incorrect. If error persists,
contact service. Service may ask you to verify DIP switch settings.
ER8 BUTTON STUCK √
ALL BUTTONS
Press each membrane key and check for proper operation. If a key doesn’t function, or
if the error persists, the membrane overlay may require replacement. Contact service.
ER9 PUMP BLOCKED √
CHECK PUMP & HOSE
Check for obstructions in drain hose. If clogged, remove hose from unit and blow hose
out with compressed air. Inspect and clean the pump check valve and pump basin. See
“Clean pump check valve and basin,” p. 5.
