Drill Master 66965 - Parts List & Assembly Diagram

Page 13For technical questions, please call 1-800-444-3353.SKU 66965
PARTS LIST & ASSEMBLY DIAGRAM
Part Description Qty
1 Screw (ST2.9 x 15) 1
2 Screw (ST2.9 x 18) 7
3 Screw (M5 x 25) 1
4 Right Case 1
5 Chuck 1
6 Gear Box 1
7 Motor Connector 1
8 Radiator 1
9 Bulb 1
10 Small Screw 1
11 Battery Pack 1
Part Description Qty
12 Wire 1
13 Direction Selector 1
14 Connector 1
15 Clamp 1
16 Screwdriver Bit 1
17  1
18 Trigger Switch 1
19 Battery Clamp 1
20 Battery Charger 1
21 Adapter 1
20
21
