21
Contents
Terminal
11
Terminal
13
Terminal
15
Terminal
16
Contents
Terminal
11
Terminal
13
Terminal
15
Terminal
16
No error off off off off
Overcurrent on off off off Option error off off off on
IGBT fault off on off off Console error off off off on
Overvoltage on on off off
Communication
error
on off off on
Overload off off on off
Insufficient
voltage
off on off on
Blown fuse on off on off External failure 1 off off on on
Start failure off on on off External failure 2 on off on on
Excess frequency on on on off External failure 3 off on on on
EEPROM error off off off on External failure 4 on on on on
No. 15 Alarm Code
Table 12 Alarm code table
4-2-16 Multifunction input terminals
Register multifunction input items shown in tables 13, 15 at each terminal. When a terminal is selected from
among code numbers 74-79, the functions shown in Tables 13, 15 are displayed at the console for easy selec-
tion.
1) No. 74 Term-24.Sel (terminal 24)
2) No. 75 Term-25.Sel (terminal 25)
3) No. 76 Term-26.Sel (terminal 26)
4) No. 77 Term-27.Sel (terminal 27)
5) No. 78 Term-28.Sel (terminal 28)
6) No. 79 Term-29.Sel (terminal 29)
When the same function is set at two or more terminals and any one of them is turned on, the condition is
assumed to be on. (OR condition)
The function which are not set at any terminal is assumed to be off. (Emergency stop B [Emrg Stop-B], how-
ever, is B contact operation. When the selected terminal is opened, emergency stop occurs.)
Multifunction terminals can be input to the six terminals
shown left.
(One of the terminals can be selected.)
}
No. Function indication Explanation
1
2
3
Preset Sel.1
Preset frequency selection
When three terminals are used, the 7 stage preset frequency can be selected.
When only preset (1) is used, specify only one terminal.
Terminal at
which
preset Sel.3
is set
Terminal at
which
preset Sel.2
is set
Terminal at
which
preset Sel.1
is set
Set-up function Code No.
OFF OFF ON Set value for preset (1) frequency (No. 03)
OFF ON OFF Set value for preset (2) frequency (No. 04)
OFF ON ON Set value for preset (3) frequency (No. 86)
ON OFF OFF Set value for preset (4) frequency (No. 87)
ON OFF ON Set value for preset (5) frequency (No. 88)
ON ON OFF Set value for preset (6) frequency (No. 89)
ON ON ON Set value for preset (7) frequency (No. 90)
Table 13 Multifunction input items 1
