List of replaceable parts
Replaceable parts are defined here as parts of the product subject to normal wear-and-tear
during usage of the product.
The replaceable parts below can be purchased from Droyd, and will include instructions on
how to replace the part(s).
Replaceable parts are not covered under the manufacturer’s warranty.
1)
Tire and rim set
2)
Headlight kit
3)
Ignition key
4)
Speed limit key
5)
Brake lever
6) Throttle twist control
Technical specifications
Model name: Weeler
SKU number: DZ02
Product type: Electric rideable product
Minimum required age of rider*: 6+ years old
Parental control Type **: ignition key and speed limit key
Number of maximum speed settings: Two (high and low)
Max weight capacity ***: 132 lbs (59.9 kg)
Distance from seat to ground: 18.3 in (46.5 cm)
Seat dimensions (LxWxH): 18.1 x 5.1 x 2.4 in (46x 13 x 6 cm)
(Seat is non-adjustable.)
Max range on a single battery charge ****: Up to 8 miles (12.9 km)
Max ride time on a single battery charge ****: Up to 45 mins
Battery type: Lithium-ion
Battery charging time from 0% to 100%: Approximately 6 – 7 hours
Total battery lifespan ****: Up to 300 charging cycles
Battery voltage: 24 V
Battery amp-hours: 8 Ah
Motor type: Brushless DC
Motor voltage: 24 V
Motor wattage: 200 W
Charger model *****: YLT-C294150
Charger input: AC 100-240V~ 50/60Hz 1.5A
Assembled product dimensions (LxWxH): 44.8 x 21.3 x 26.8 in
(113.8 x 54.1 x 68.1 cm)
Tire diameter: 14 in (35.5cm)
Wheel rim diameter: 11 in (28 cm)
Battery level indicator type: LED light indicator
Brake type: Rear drum brake
Assembled product weight: 40.3 lbs (18.3 kg)
Total package weight: 50.71 lbs (23 kg)
Certifcate of compliance and testing: ASTM F963 and UL2272
Parental control enabled? : YES
High speed setting:10 mph (16 kph)
Low speed setting:6.2 mph (10 kph)
Charger output: DC 29.4V ? 1.5A
Charger manufacturer: Shenzhen Yongletong Electronic Technology Co., Ltd
