DSC 3G2080E

Regulatory Information
Modification Statement
DigitalSecurity Controls has not approved any changes ormodifications to this device by the user. Anychanges ormodifications could void the user’s
authorityto operate the equipment. DigitalSecurityControls n’approuve aucune modification apportée à l’appareilpar l’utilisateur, quelle qu’en soit la
nature. Tout changement ou modification peuventannulerle droit d’utilisation de l’appareilpar l’utilisateur.
Interference Statement
Thisdevice complieswith Part 15 of the FCC Rulesand Industry Canada licence-exempt RSSstandard(s). Operation issubjectto the following two con-
ditions: (1) thisdevice maynot cause interference, and (2) this device must accept anyinterference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareilsradio exempts de licence. L'exploitation est autorisée aux
deuxconditions suivantes: (1) l'appareil ne doit pasproduire de brouillage, et (2) l'utilisateurde l'appareildoit acceptertout brouillage radioélectrique
subi, même sile brouillage est susceptible d'en compromettre le fonctionnement.
Wireless Notice
Thisequipment complieswith FCC and IC radiation exposure limitsset forth for an uncontrolled environment. The antenna should be installed and oper-
ated with minimumdistance of 20 cm between the radiator and yourbody. Thistransmitter must not be co- located oroperating in conjunction with any
otherantenna ortransmitter.
Cet appareilest conforme auxlimites d'exposition auxrayonnementsde la IC pourun environnement non contrôlé. L'antenne doit être installé de façon
à garder une distance minimale de 20 centimètresentre la source de rayonnementset votre corps. L'émetteurne doit pasêtre colocalisé ni fonctionner
conjointement avecà autre antenne ou autre émetteur.
Antenna gain mustbe below / Gain de l'antenne doit être ci-dessous:
Frequency Band/Bande de fréquence TL2803GRE, TL2803GE, 3G2080RE, 3G2080E TL280LE, TL280LER, LE2080, LE2080R
GSM850 /FDD V 2.26 dBi -
PCS1900 / FDD II 2.41 dBi -
LTEB2 - 2.76 dBi
LTEB4 - 2.82 dBi
LTEB5 / B12 / B13 - 2.45 dBi
FCC Class B digital device notice
Thisequipment has been tested and found to complywith the limits fora ClassBdigital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmfulinterference in a residential installation. Thisequipment generates usesand can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference willnot occur in a particularinstallation.If thisequipment does cause harmfulinterference to radio or
television reception, which can be determined byturning the equipment off and on, the userisencouraged to tryto correct the interference byone or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipmentand receiver.
-Connect the equipment into an outleton a circuit different fromthat to which the receiverisconnected.
-Consult the dealeroran experienced radio/TVtechnician forhelp
CAN ICES-3 (B) / NMB-3 (B)
TL2803G(R)E -EU /3G2080(R)E- EU/TL280(R)E
LE2080(R)/TL280LE(R)
FCC ID:F5316TL2803GRE FCC ID:F5317TL280LER
IC: 160A-TL2803GRE IC:160A-TL280LER
Notes for EN50131-1:2006/A1:2009 Compliant installations:
ModelsTL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E/TL280LE-EU/LE2080-EU are an SPT Type Y. The module ismounted within CIEorPS housing
and it receivespowerfromthe compatible CIEor PowerSupplysource that are in compliance with EN50131-6:2017 Type Arequirements fora Grade 2,
ClassII application.This product has no replacement partsand software programmable optionsare accessible at level3 (installermode), section [851].
The TL2803G(R)E-EU/3G2080 (R)E-EU/TL280 (R)E/TL280LE-EU/LE2080-EU connectsto compatible DSC alarm controlpanelsusing the DSC pro-
prietaryserial interface and protocol PC-Link(converted also to RS- 422). The module operates in pass-through mode and itdoes acknowledge the
alarmto the compatible controlpanelafteran acknowledgement hasbeen received fromthe compatible alarmreceiver
1.The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E/TL280LE-EU/LE2080-EU module ismonitored bythe controlpaneland itis programmed via the
programming menu (* 8, section [851] in the control panel. The interface is connected to the PC- Link busas shown in the diagram included in this
manual.
2.The HSPA3G/LTECellularpath isimmune to conducted and radiated RF fieldswith levelsup to 10V/mastested perEN50130-4 Standard.
3.The TL2803G(R)E-EU/3G2080(R)E- EU/TL280(R)E/TL280LE- EU/LE2080-EU module conforms with radiated emissions levels forClass B equip-
ment asper standards EN61000-6-3/EN55022/CISPR32.
4.The TL2803G (R)E-EU/3G2080(R) E-EU/TL280 (R)E/ TL280LE-EU/LE2080-EU module uses AES128 encryption and heartbeat supervision for
HSPA3GLTE Cellular communication paths and it meets security levels S2 as per EN50136-2:2013. It also uses authentication for each message
exchanged with the compatible receiver equipment at ARC and it meetsleveI 2 for information security.
5. The 3G2080 (R) E- EU/LE2080- EU module has only one communication path: HSPA3G or LTE Cellular communication path using
900/1800/2100MHzor LTE PublicCellular Network. The HSPA3G/LTE Cellular communication path that can be used in a standalone mode in con-
junction with a DSC alarmsystem(compatible DSC alarmcontrolpanelmodels: HS2128/064/032/016). The supported ATSconfiguration is: SP4.
6.The TL280(R)Emodule hasonlyone communication path: Ethernet communication path using Internet.The communication path that can be
used in a standalone mode in conjunction with a DSC alarmsystem(compatible DSC alarmcontrolpanelmodels: HS2128/064/032/016).
The supported ATSconfiguration is:SP4.
7.The TL2803G (R)E-EU/TL280LE-EU module hastwo communication paths: HSPA3G/LTECellularcommunication path using 900/1800/2100MHz
LTEPublic Cellular Networkand Ethernet communication path using Internet. The communication paths can be used in a standalone mode in con-
junction with a DSC alarm system (compatible DSC alarm control panel models: HS2128/064/032/016). The supported ATS configuration is:SP4 or
DP3.
8.TL2803G(R)E-EU/3G2080 (R)E-EU/TL280(R)E/ TL280LE-EU/LE2080-EU has been tested for compliance in conjunction with the following applic-
able standards:EN50136-1:2012 + A1:2018, EN50136-2:2013,EN50131-10:2014, ATSconfiguration: SP4, DP3
ForEN50131-1:2006/A2:2017 compliant installations, the following programming optionsshallbe setasdescribed. Supervision Heartbeat: shallbe set
to 180 seconds
69
