ATS Custom Category C Level

EN50136-1:2012 +A1:2018 Table 2 – Transmission time SPT according to SP4 and DP3

EN50136-1:2012 +A1:2018 Table 3 – MaximumReporting Time SPTaccording to SSPT according to SP4 and DP3P4 and DP3

EN50136-1:2012 +A1:2018 Table 7 – ATSN availability SPTaccording to SP4 and DP3 (depending on cellularcarrierused)

EN50136- 1:2012 + A1:2018 Table 8 – SPT substitution security

requirements

SPTaccording to SP4 and DP3 (use AES-128 and authentication/sequential

information in each message transmitted to the SGreceiver)

EN50136- 1:2012 + A1:2018 Table 9 – SPT information security

requirements

SPTaccording to SP4 and DP3 (use AES-128 encryption)

EN50136-1:2012 +A1:2018 Table 1 – ATSconfiguration

Use single communication path for models 3G2080 (R) E- EU/LE2080-EU

(cellularnetwork),TL280(R)E(Ethernet port)(SPT according to SP4)and two

communication paths for model TL2803G (R) E- EU/TL280LE- EU

(cell/Ethernet). (SPT according to SP4 orDP3)

EN50136-1:2012 +A1:2018 Table 4 – RCT to AEalarmreporting ATSfailure reported to ARC, SPT according to SP4 and DP3

EN50136-1:2012 +A1:2018 Table 5 – SPTto ASalarmreporting

ATS failure reported to AS (DSC compatible control panel

HS2128/HS2064/HS2032/HS2016). SPT according to SP4 and DP3

EN50136-1:2012 +A1:2018 Table 6 – ATSavailabilityrecording There isno recording of availabilityfailure

EN50136-2:2013 Table 1 No logging function provided

EN50136-2:2013 Table 2 No memoryprovided forlogging function

EN50136-2:2013 Table 3 ATSfailure reported to ARC

SIMPLIFIED EU DECLARATION OF CONFORMITY

Hereby,Tyco Safety Products Canada Ltd declaresthat the radio equipmenttype isin compliance with Directive 2014/53/EU. The fulltext of the EU declar-

ationsof conformityforthe modelsmentioned below are available atthe following internetaddresses:

TL2803G(R)E-EU -http://dsc.com/pdf/1605003

3G2080(R)E-EU -http://dsc.com/pdf/1605004

TL280LE-EU -http://dsc.com/pdf/2112001

LE2080-EU -http://dsc.com/pdf/2112002

Operating frequency bands and related max radio-frequency power transmitted:

NOTE:The compatible receiver at ARC location shallhave supervision window programmed for180 seconds. TL2803G(R)E-EU/3G2080(R)E-EU/TL280 (R)

E/ TL280LE-EU/LE2080-EU has been certified by TELEFICATION in accordance with EN50131-1:2006/A2:2017, EN50131- 10:2014 requirements for

Grade 2, ClassII and EN50136-2:2013 ATSCustomCategoryC according to SP4 and DP3.

Frequency Band Maximum Power

EGSM900 890.0MHz- 914.8MHz Class4 (2W) @ 900MHz, GSM

EGSM900 880.2MHz-889.8MHz Class1(1W)@ 1800MHz,GSM

DCS1800 1710.2MHz-1784.8MHz ClassE2 (0.5W)@ 900MHz, EDGE

WCDMA(Band VIII) 882.4MHz-912.6MHz ClassE2 (0.4W)@ 1800MHz, EDGE

WCDMA2100 (Band I)1922.4MHz-1977.6MHz Class3 (0.25W)@ 900/2100MHz, WCDMA

LTE25dBm Class3@700(FDD28)/800(FDD20)/900 (FDD8)/1800(FDD3)/2100(FDD1)/2600(FDD7) MHz

OnlymodelsTL2803GRE-EU,TL2803GE-EU, 3G2080RE-EU, 3G2080E-EU, TL280LE-EU and LE2080-EUare CEcompliant.

European single point ofcontact: Tyco SafetyProducts, Voltaweg 20, 6101XK, Echt,Netherlands

UL/ULC Installation Requirements

NOTE:For equipment used at the protected premisesand intended to facilitate IPcommunications(hubs, routers, NIDs, DigitalSubscriber Line (DSL), cable

modems), 24 hourbackup poweris required. Where such cannot be facilitated, a secondary(back-up)communication channelisrequired.

Domain Name Service (DNS) programming is not permitted in UL1610 listed systems.

Technical Specifications

The input voltage to the Communicator can be drawn fromthe UnderwritersLaboratories/UnderwritersLaboratoriesCanada (UL/ULC)listed controlpanel.

Notes for using Private, Corporate, and High Speed Data Networks:

Networkaccessand domain access policiesshall be set to restrict unauthorized network access, and spoofing or Denialof Service (DoS) attacks. Select an

Internet Service Provider (ISP) that has redundant servers/systems, back-up power, routers with firewalls enabled, and methods to identify and protect

against DoSattacks(e.g., via spoofing).

Notes for using Public Switched and Cellular Data Networks:

Communication channels shall be facilitated such that the communicator willrestrict unauthorized access,which could otherwise compromise security. The

communicator shallbe located in a secured area.

•ForULC Residential Fire and Burglary applicationsthe TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R) /TL280LE(R) can be used asprimary com-

munication channel via either cellularor Ethernet or as a back-up in conjunction with the Digital AlarmCommunicator Transmitter(DACT). Test transmission

every24 hoursshallbe enabled on each channel.

•ForULC Commercial Fire and Burglary applicationsthe TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R) /TL280LE(R) can be used asa passive

communication module with the following securitylevels:

l P1 (each channelcellularorEthernet isindependent)

l P2 (cellularand Ethernet in back-up configuration, panelsection [851][005] toggle option [5] OFF).

l P3 (cellularand Ethernet in redundant configuration,panelsection [851][005] toggle option [5] ON).

The communicator can also be used as an active communication systemwith the security levels A1-A4 (each channelcellular or Ethernet independent or

togetherin a back-up/redundant configuration).For active line security systemsAES128 bit encryption shallbe enabled (at the monitoring station receiver)
