10 Managing Partitions
39
10.2 Fire and CO Zone Types
• If a Fire zone generates an alarm only the partition the fire zone is assigned to will go into alarm.
Other partitions retain their current state.
• If the [F] key on a global keypad is used to generate an alarm all enabled partitions will go into alarm.
• One or more fire keypads may be located on any partition.
• On alarm, the fire auto-scroll display appears on all partition keypads and on all global keypads. Fire
alarm silence and fire system reset may be done directly on any partition keypad. To silence a fire or
CO alarm from a global keypad requires that the global keypad be loaned to one of the partitions.
R Partition is ready to be armed.
N Partition is not ready to be armed.
! Partition is in alarm.
- Partition is not configured
A Partition is armed.
Table 10-1 Partition Flags (Continued)
LCD Display Flag Description
