4
3 Assembly description
The LC-151 is a robust yet small detector which includes a large LED indicator that can be easily
observed from long distances to provide indication of intrusion. Using the supplied mounting
bracket, the LC-151 can be easily mounted to walls using the provided mounting screws. For
installations requiring the detection beam to be adjusted horizontally or vertically to obtain the
desired field of protection use the LC-B1-15X Outdoor Mounting Bracket pictured below. (not
included)
LC-151 Outdoor Motion Detector
LC-B1-15X Outdoor Mounting Bracket
The LC-151 consists of two detection elements:
• PIR element
• Microwave element
The following drawing shows all internal elements:
Detection LED control jumper
(Factory setting: ON)
Tamper switch
Microwave Do
