[971] - EEPROM Map Version
[972] - Virtual Keypad Language Version
[976] - Radio Configuration File Version
[977] - Cellular Network Provider - MCC/MNC Code
[978] - Cellular Network Type
00 GPRS 2G 04 LTE 4G
01 EDGE 2G 05 LTE Advanced 4G
02 WCDMA 3G 06 CDMA 2G
03 HSDPA 3G 07 EVDO 3G
[979] - Cellular Network CSQ
[980] - Radio Reset Codes
[981] - Radio Type
[982] - Radio Firmware Version
[983] - Firmware Update Diagnostics Section
Firmware updates for panel and the communicator itself can be made from the communicator.
Table 14: Response Code Descriptions and Corresponding Actions
Response
Code
Description of Response Code Corresponding Action
Bad File
00 Version check failed
Contact DSC Tech Support, described the action
attempted with the system and supply them with the
Response Code in Section [983].
01 Image type mismatch
02 Device type mismatch
03 Hardware type mismatch
04 General variant mismatch
05 Firmware header wrong length
Panel is Busy
20
System update pending - panel is
armed
Disarm the panel to continue with system firmware
update process.
21
System update pending -AC trouble
(Any AC trouble; device/module)
Resolve the AC trouble to continue with system
firmware update process.
22
System update pending -low battery
(Any low battery trouble;
device/module)
Resolve the low battery trouble to continue with
system firmware update process.
25
System update pending -
communication in progress
Retry in a few minutes; if issue persists, contact DSC
Tech Support.
Firmware Update Sequence Change
A0 System firmware update successful None
A1 System firmware update failure
At least one module was not updated. Use DLS to
reapply the firmware to the module not updated.
A2
System firmware update failure -
module not found
At least one module was not responding during
firmware update. Ensure all modules enrolled are
physically connected and powered up.
AA Device firmware transfer begin None
AB
Device firmware module update
begin
None
39
