DSC LE2080 Installation Manual

Ratings Compatibility
Table 1: Communicator Ratings
Model
3G2080(R)E /LE2080
(R)
Cellular only
TL280(R)E
Internet only
TL2803G(R)E/TL280LE
(R)
Internet and Cellular
Power Supply Ratings
Input Voltage
10.8-12.5 VDC
Power is supplied from the panel’s PC-Link header or PCL-422 module in remote
cabinet installations. In remote cabinet installations, the PCL-422 module located
with the communicator is powered by an HSM2204 or an HSM2300. Refer to the
PCL-422 installation sheet for details.
Current Consumption
Standby Current 90mA @ 13.66V 120mA @ 13.66V
Alarm (Transmitting)
Current
400mA @ 12V
Operating
Frequency
850MHz, 1900MHz
Typical Antenna
Gain
2dBi
Environmental Specifications
Operating
Temperature
-10°C to 55°C
Humidity 5% ~ 93% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions
(mm)
100 × 150 × 15 100 × 150 × 15
Weight (grams) with
bracket
310 320
Table 2: Compatible Receivers and Panels
Communicator Receiver/Panel Description
3G2080(R)E
LE2080(R)
TL2803G(R)E
TL280LE(R)
TL280(R)E
Receiver
l Sur-Gard System I-IP Receiver, version 1.13+
l Sur-Gard System II Receiver, version 2.10+
l Sur-Gard SG-DRL3-IP, version 2.30+ (for Sur-Gard System III
Receiver)
l Sur-Gard SG-DRL4-IP version 1.20+ (for Sur-Gard System IV
Receiver)
l Sur-Gard SG-DRL5-IP version 1.00+ (for Sur-Gard System 5
Receiver)
Panel
l HS2016
l HS2016-4
l HS2032
l HS2064
l HS2128
NOTE: Enter [*][8][Installer Code][900] at keypad to view the panel version number.
Pre Installation Configuration
Encryption
The communicator uses 128 Bit AES encryption. Encryption can only be enabled from the monitoring sta-
tion receiver. Each receiver (Ethernet 1 and 2, cellular 1 and 2) can independently have encryption
7
