DSC LE2080 Installation Manual

General
IMPORTANT
This installation manual shall be used in conjunction with the control panel. All the safety instructions spe-
cified within that manual shall be observed. The control panel is referenced as the “panel” throughout this
document. This installation guide provides the basic wiring, programming and troubleshooting inform-
ation.
The HSPA(3G)/dual-path alarm communicator is a fixed, wall-mounted unit, and shall be installed in the
location specified in these instructions.The equipment enclosure must be fully assembled and closed,
with all the necessary screws/tabs, and secured to a wall before operation. Internal wiring must be
routed in a manner that prevents:
l Excessive strain on wire and on terminal connections,
l Interference between power limited and non power limited wiring,
l Loosening of terminal connections, or
l Damage of conductor insulation.
WARNING: Never install this equipment during a lightning storm!
Safety Information
The installer must instruct the system user on each of the following:
l Do not attempt to service this product. Opening or removing covers may expose the user to dan-
gerous voltages or other risks.
l Any servicing shall be referred to service persons only.
l Use authorized accessories only with this equipment.
l Do not stay close to the equipment during device operation.
l Do not touch the external antenna.
Model Information
This manual covers the following models of alarm communicators:
Models TL2803GRE, TL2803GE, 3G2080RE, 3G2080E, TL280RE and TL280E are for North Amer-
ica and cover the following bands: 850 / 1900MHz.
Models TL2803GRE- EU , TL2803GE- EU , 3G2080RE- EU and 3G2080E- EU are for Europe/In-
ternational and cover the following bands: 900/1800 MHz.
Models TL280LER , TL280LE, LE2080R , LE2080 are for North America and support LTE bands B2,
B4, B5, B12 and B13 and WCDMA bands B2 and B5.
Band Transmit Band (Tx) Receive Band (Rx)
LTE B2 1850 - 1910 MHz 1930 - 1990 MHz
LTE B4 1710 - 1755 MHz 2110 - 2155 MHz
LTE B5 824 - 849 MHz 869 - 894 MHz
LTE B12 698 - 716 MHz 728 - 746 MHz
LTE B13 777 - 787 MHz 746 - 756 MHz
UMTS B2 1850 - 1910 MHz 1930 - 1990 MHz
UMTS B5 824 - 840 MHz 869 - 894 MHz
References to model names TL280(R)E, TL2803G(R)E, 3G2080(R)E, TL280LE(R) and LE2080 (R)
throughout this manual apply to all specified models unless stated differently. Models ending in “R”
include a built-in RS-232 interface for connecting to local third party applications.
The TL280(R) E/TL2803G(R)E/3G2080(R) E/TL280LE(R) /LE2080(R supports integration over cel-
lular/IP, available with licensed 3rd party product solutions. Specific programming for the related pro-
gramming sections is to be provided by the 3rd party. A current list of compatible 3rd party solutions can
be found at www.dsc.com.
3G2080(R)E: Is a HSPA(3G) cellular alarm communicator that sends alarm communication to Sur- Gard
System I-IP, II, III (SG-DRL3IP), IV (SG-DRL4IP), and 5 (SG-DRL5IP) central station receivers via a
HSPA(3G)/GPRS digital cellular network. TL2803G(R)E: Is a dual-path HSPA(3G) Ethernet alarm com-
municator that sends alarm communication to Sur- Gard System - IPI, II, III, IV, and 5 central station
receivers through Ethernet/Internet or a HSPA(3G)/GPRS digital cellular network.
TL280(R)E: Is an Ethernet alarm communicator that sends alarm communication to Sur-Gard System I-
IP, II, III (SG-DRL3IP), IV (SG- DRL4IP), and 5 (SG- DRL5IP) central station receivers via Eth-
ernet/Internet.
5
