37
[390]-[393] LINKS Preambles
Downloading can be performed through the LINKS1000
cellular communicator if the telephone line is discon-
nected. If using the LINKS1000 with Call Back, you need
to program the LINKS1000 Preamble with the download-
ing telephone number in order for the panel to call the
computer correctly.
LINKS1000 Cellular Communicator
The LINKS1000 cellular communicator can be used three
different ways: as the sole communicator for the panel, as
a backup for either or both telephone numbers, or as a
redundant backup to the land line communicator (the
panel will call both the land line and via the LINKS1000).
A LINKS1000 Preamble
LINKS1000 Preamble LINKS1000 Preamble
LINKS1000 Preamble is programmable for each tele-
phone number in the event that the land line number is
local but the LINKS1000 is required to dial an exchange.
When programming a LINKS1000 Preamble, all unused
digits must be programmed with a Hex decimal ’F’.
Sole Communicator
The panel can be programmed to report only using the
LINKS1000 cellular communicator when an event occurs.
To program this select only the LINKS1000 for the Com-
Com-Com-
Com-
municator Call Direction
municator Call Direction municator Call Direction
municator Call Direction Options for the event. In addi-
tion the Call LINKS1000 as well as Land Line
Call LINKS1000 as well as Land Line Call LINKS1000 as well as Land Line
Call LINKS1000 as well as Land Line option must
also be enabled. When the selected event occurs the panel
will only attempt to call the central station using the
LINKS1000.
NOTE:
If a LINKS1000-only event fails to communicate, the
LINKS1000 must successfully communicate a LINKS1000-only
event in order for the FTC Trouble to clear.
Backup Communicator
The panel can be programmed to call using the
LINKS1000 cellular communicator if the panel is having
difficulty communicating an event using the land line. To
program this select the telephone number and
LINKS1000 options for the Communicator Call Direction
Options for the event. The LINKS1000 is backup of Land
Lines option must also be selected.
When used as a backup communicator the panel will
attempt to call the central station in the following manner:
• the panel will try to call using land lines - if unsuc-
cessful the panel will try to call using the LINKS1000
• if unsuccessful the panel will try to call using the land
lines
• if unsuccessful the panel will try to call using the
LINKS1000
This process will continue until the panel has successfully
communicated with the central station or the Maximum
MaximumMaximum
Maximum
Dialing Attempts
Dialing Attempts Dialing Attempts
Dialing Attempts has been reached.
Redundant Communicator
The panel can be programmed to call using the land line
and the LINKS1000 cellular communicator when an event
occurs. To program this select both the telephone number
and the LINKS1000 options for the Communicator Call
Communicator CallCommunicator Call
Communicator Call
Direction
Direction Direction
Direction Options for the event. In addition the Call
CallCall
Call
LINKS1000 as well as Land Line
LINKS1000 as well as Land Line LINKS1000 as well as Land Line
LINKS1000 as well as Land Line option must be selected.
The panel will call the LINKS1000 and then call the land
line when reporting the selected event.
LINKS1000 Special Preamble*
In some areas of North America, dialing #DAT or *DATA
reduces the cellular billing increment. The LINKS1000 Spe-
LINKS1000 Spe-LINKS1000 Spe-
LINKS1000 Spe-
cial Preamble
cial Preamble cial Preamble
cial Preamble (section [393]), allows the use of [*] and [#]
characters for the programming of #DAT and *DATA. The
LINKS1000 Special Preamble is sent BEFORE the Preamble
programmed in Sections [390] to [392]. Example: [Special
Preamble][Regular Preamble][Telephone Number].
NOTE:
If this Special Preamble is programmed, it will be
inserted before the Regular Preamble of ALL telephone num-
bers. Hex digits D and E are not supported for Preamble pro-
gramming. If Busy Tone Detection is enabled, the LINKS1000
must be tested to ensure full operation.
Refer to the LINKS1000
Installation Manual
for more
information and connection diagrams.
* Do not use this section for Central and Remote Fire Appli-
cations.
(Downloading Telephone Number) . . . . . . . . . . . . . . . Section [490]
Communicator Call Direction Options . . . . . Section [351] to [376]
Call LINKS1000 as well as Land Line. . . . . Section [380], Option [7]
Maximum Dialing Attempts . . . . . . . . . . . . . . . . . . . . Section [165]
This 4-digit number can be used with long distance tele-
phone numbers that are dialed through the LINKS mod-
ule. These codes are used for programming area codes in
cases where a land line telephone number may be a local
call, while the cellular telephone number dialed by the
LINKS module is a long distance call.
[393] - LINKS Special Function Preamble
This Special Preamble is inserted before all other pream-
bles. It is used for dialing such cellular numbers as #DAT
and *DATA for reduced billing increments.
5.7 Downloading Options PWS Sect 7
Downloading
Downloading allows programming of the entire control
panel via a computer, modem and telephone line. All
functions and features, changes and status, such as Trou-
ble conditions and open zones can be viewed or pro-
grammed by downloading.
NOTE:
When power is applied to the panel, a 6-hour down-
loading window can be enabled. This will allow you to per-
form downloading without having to do any keypad
programming.
NOTE:
When an event occurs that the system is pro-
grammed to communicate to the central station, the panel
will disconnect from the downloading computer and report
the event. This will happen for all events except test trans-
missions.
If the Answering Machine/Double Call
Answering Machine/Double Call Answering Machine/Double Call
Answering Machine/Double Call option is enabled
(or during the first 6 hours after power up) the panel will
answer incoming calls for downloading provided the fol-
lowing conditions occur:
1. The panel hears one or two rings, then misses a ring.
2. At this point the panel will start a timer.
3. If the panel hears another ring before the Answering
Answering Answering
Answering
Machine Double Call Timer
Machine Double Call TimerMachine Double Call Timer
Machine Double Call Timer expires it will answer on
the first ring of the second call.
The panel will immediately go on-line and begin the
download process unless the Call Back
Call BackCall Back
Call Back option is enabled.
If enabled, the panel and computer will both hang up.
The panel will then call the Download Computer Tele-
Download Computer Tele-Download Computer Tele-
Download Computer Tele-
phone Number
phone Number phone Number
phone Number and wait for the computer to answer.
Once the computer answers downloading will begin.
If the User-enabled DLS Window
User-enabled DLS Window User-enabled DLS Window
User-enabled DLS Window option is ON, the user
can activate the downloading feature by entering
[*][6][Master Code][5].
Six hours after power-up, the panel will not answer
incoming calls unless the Answering Machine/Double
Answering Machine/DoubleAnswering Machine/Double
Answering Machine/Double
Call
Call Call
Call option is enabled, or the Number of Rings
Number of Rings Number of Rings
Number of Rings is pro-
grammed to be more than [0].
If the User-Initiated Call-Up
User-Initiated Call-UpUser-Initiated Call-Up
User-Initiated Call-Up option is enabled, the user
can have the panel initiate a call to the downloading com-
puter by pressing [*][6][Master Code][6].
