Section 1: Introduction
1.1 About the PC1555 CP-01 System
The PC1555 CP-01 is a high end security system. It sup-
ports up to 32 zones, and 32 users.
The user interface is simple and easy to use. The
LCD5500Z/LCD5520Z keypad guides users through
their available options with easy-to-understand prompts.
The status of the PC1555 CP-01 system can be monitored
over telephone lines, or using an alternative communicat-
ing device, including LINKS1000, LINKS2X50,
LINKS3000, Skyroute™ and DVACS*.
The PC1555 CP-01 main board comes with 2 programma-
ble outputs, and you can add up to 12 more using PC5204
and PC5208 modules. You can program the outputs to
control things such as doorstrikes and lights, using 25 dif-
ferent output options. See ‘Programmable Outputs’ in
Section 5.
You can program the PC1555 CP-01 using any system
keypad, or using DLS2002 downloading software and a
computer. See ‘How to Program’ on page 10.
Review the complete PC1555 CP-01 manual set before
installing the PC1555 CP-01 security system.
1.2 About the PC1555 CP-01 Manual Set
Installer Manuals
Read the entire manual carefully before beginning your
installation.
This manual describes:
• An overview of the system (Section 1: ’Introduction’)
• How to install and wire the system and its modules
(Section 2: ’Installation and Wiring’)
• How to program the system (Section 3: ’How to Pro-
gram’)
• An introduction to the user interface and keypad oper-
ation (Section 4: ’Keypad Commands’)
• An overview of the main system programming sec-
tions (
Section 5
: ’Programming Sections’).
Be sure to record all your system programming in the
Pro-
Pro-Pro-
Pro-
gramming Worksheets
gramming Worksheetsgramming Worksheets
gramming Worksheets
.
If you will be adding modules to your PC1555 CP-01 sys-
tem, read the
Installation Instructions
Installation InstructionsInstallation Instructions
Installation Instructions
that come with each
module.
User’s Guide
One User’s Guide comes with the PC1555 CP-01 system.
The
User’s Guide
User’s GuideUser’s Guide
User’s Guide
provides easy to follow instructions for
end-users. Installers should also review this manual, in
order to properly instruct the end-users once the installa-
tion is complete.
1.3 Main Panel Specifications
Flexible Zone Configuration:
• 6 fully programmable zones
• 39 access codes: 32 user, 1 system master, 2 supervisor
codes, 2 duress, 1 maintenance and 1 installer code
• Expandable to 32 zones
• Keypads with zone inputs available ( PC5516Z,
PC5532Z, LCD5500Z/LCD5520Z, and LCD5501Z)
• Wireless expansion available using the PC5132 wire-
less 32 zone expansion module (433 or 900MHz, fully
supervised)
• Normally closed, Single EOL, or Double EOL zone
supervision
• 34 zone types, 8 programmable zone options
Audible Alarm Output:
• 700mA supervised bell output (current limit 3 Amps),
12 V
DC
• Steady or pulsed output
EEPROM Memory:
• Will not lose programming or system status on com-
plete AC and battery failure
Programmable Outputs:
• Up to 14 programmable outputs, 21 programmable
options
• One low current (50 mA) PGM output on main panel
(PGM1)
• One high current (300 mA) PGM output with 2-wire
smoke detector capability on main panel (PGM 2)
• Eight additional low current (50 mA) PGM outputs
available using the PC5208 module
• Four high current (1 Amp) PGM outputs available using
the PC5204 module (1 PC5204 output, fully supervised
for siren output)
Powerful 1.5 Amp Regulated Power Supply:
• 550 mA auxiliary supply, 12 V
DC
• Positive temperature coefficient (PTC) components
replace fuses
• Supervision for loss of AC power, low battery
• Internal clock locked to AC power frequency
NOTE:
For 24-hr standby, maximum Aux capacity is 420mA.
Power Requirements:
• Transformer = 16.0 V
AC
, 40VA (min) permanently
connected
• Battery = (2) 12 volt 7Ah (min.) rechargeable sealed lead
acid
or (1) 12 volt 4Ah battery (for Burglary applications only)
• PC5010 CP-01 current draw: 65mA
Remote Keypad Specifications:
• Various keypads are available:
- PC5508Z 8 Zone LED keypad
- PC5516Z 16 Zone LED keypad
- PC5532Z 32 Zone LED keypad
- LCD5500Z/LCD5520Z Liquid Crystal Display keypad
- LCD5501Z LCD-style keypad
- LCD5501Z32-900/LCD5501Z32-433 keypad/receiver
• ’Z’ version keypads have one zone input
• Each keypad has 5 fully programmable function keys
• Connect up to 8 keypads
• Four wire (Quad) connection to Keybus
• Built in piezoelectric buzzer
Digital Communicator Specifications:
• Supports all major formats including SIA, Contact ID,
and Residential Dial
• Split reporting of selected transmissions to each tele-
phone number
• 3 programmable telephone numbers
• 1 system account number, plus a partition account
number
• Supports LINKS1000, GSM1000 cellular communica-
tion, Links 2X50 long range alarm transmitter and Sky-
route™ Cellemetry communication transceiver
• DTMF and pulse dialing
•DPDT line seizure
*DVACS is a registered trademark of Electro Arts Limited.
