Page #27 background imageLoading...
Page #27 background image
Program Descriptions: 5.12 Telephone Line Monitor (TLM)
23
NOTE: If you program more than one PGM output as the same
output type (e.g. if PGM1 and PGM2 are both programmed as
[19] Command Output 1), the settings for output attributes [1],
[2] and [5] must be the same. This does not apply to outputs
programmed as types [09] and [10].
PGM Output Attributes . . . . . . . . . . . . . .Section [141]-[142]
5.12 Telephone Line Monitor (TLM)
When the TLM Enable option is selected, the panel will super-
vise the telephone line and will indicate a trouble condition if
the telephone line is disconnected.
If the TLM Enable option is ON, the panel will check the tele-
phone line every 10 seconds. If the telephone line voltage is
below 3V for the number of checks programmed in the TLM
Trouble Delay section, the panel will report a TLM trouble.
The default number of checks is 3. Enter a number from [003]
to [255] in the TLM Trouble Delay section to change the num-
ber of checks before the TLM trouble is reported. Program-
ming a delay means that a momentary interruption of the
telephone line will not cause a trouble condition.
If the TLM Trouble Beeps When Armed option is enabled,
the panel will indicate a TLM trouble at the keypad while the
system is armed. To activate the bell output in the case of a
TLM trouble while the system is armed, the TLM Audible
(Bell) When Armed option must be selected.
When the trouble condition is restored, the panel can send a
TLM Restoral reporting code. Any events which occur while
the telephone line is down will also be communicated.
If the LINKS1000 Cellular Communicator, or LINKS2X50 is
being used, the panel can be programmed to report a TLM
Trouble Reporting Code.
TLM Enable/Disable . . . . . . . . . . . . . . . . . . Section [015]: [7]
TLM Trouble Beeps When Armed or
TLM Audible (Bell) When Armed . . . . . . . . Section [015]: [8]
TLM Trouble Reporting Code . . . . . . . . . . . . . . Section [349]
TLM Restoral Reporting Code . . . . . . . . . . . . . Section [350]
TLM Trouble Delay . . . . . . . . . . . . . . . . . . . . . . Section [370]
5.13 Bell
The bell will silence after the number of minutes programmed
for the Bell Cut-off time have passed.
The panel supervises the Bell output. If an open condition is
detected, the panel will immediately indicate a trouble condi-
tion by beeping the keypad twice every 10 seconds to alert
the owner of the problem. The panel can send a Bell Circuit
Trouble and Trouble Restoral reporting codes to indicate the
situation (See 5.8
“Communicator – Reporting Codes
on
page 18.)
If the Temporal Three Fire Signal option is enabled, all Fire
signals (on zone types [07], [08], [87], [88]) will follow the
Temporal Three Pattern as described in NFPA 72. If turned
OFF all Fire signals will sound a one second on, one second
off cadence.
If Fire Bell Continuous is enabled, the alarm output will
sound until a code is entered. If disabled, the alarm will sound
until a code is entered or the bell cut-off time has expired.
Bell Cut-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . Section [005]
Bell Circuit Trouble Reporting Code. . . . . . . . . Section [349]
Bell Circuit Trouble Restoral Reporting Code. . Section [350]
Temporal Three Fire Signal Enable/Disable.Section [013]: [8]
Fire Bell Continuous. . . . . . . . . . . . . . . . . . .Section [014]: [8]
5.14 Test Transmission
To ensure that the communication link with the central station
is functioning properly, program the panel to send a test trans-
mission signal on a regular basis.
The panel can send a Periodic Test Transmission Reporting
Code at the programmed Test Transmission Time of Day.
The Test Transmission Cycle determines the period of time
between tests. The option Land Line Test Transmission in
Minutes/Days allows you to select whether the Land Line Test
Transmission cycle will be counted in minutes or days. If you
have selected the test transmission cycle to be in minutes, the
Test Transmission Time of Day counter will not apply.
NOTE:If you have selected the Land Line Test Transmission in
Minutes option, do not program the test transmission cycle to
be less than 10 minutes.
NOTE:The LINKS Test Transmission can only be programmed
in days.
If you program the test transmission cycle for a longer period
of time than it was programmed for previously, the system will
wait the original time period before the next test transmission
is sent, and then begin reporting with the new interval.
The panel can also send a test for the LINKS1000 Cellular
Communicator, if used. If the LINKS1000 Test Transmission
Code is programmed, the panel will send a cellular test at the
interval programmed in the LINKS Test Transmission Cycle.
Users can also generate a communicator test. If the System
Test Reporting Code is programmed, the panel will send the
signal when the System Test keypad command is entered.
(See
“[*][6] User Functions
on page 10.)
Test Transmission Reporting Codes . . . . . . . . . Section [352]
Test Transmission Time of Day . . . . . . . . . . . . . Section [371]
Test Transmission Cycles. . . . . . . . . . . . . . . . . .Section [370]
Land Line Test Transmission M/D . . . . . . . .Section [702]: [3]
5.15 Transmission Delay
If the transmission delay zone attribute is selected for a given
zone, the panel will delay reporting an alarm for that zone for
the number of seconds programmed for the Transmission
Delay Time. If the panel is disarmed before the delay time
expires, the panel will not report the event.
Transmission Delay Time . . . . . . . . . . . . . . . . . .Section [370]
5.16 Fire, Auxiliary and Panic Keys
The emergency keys are available on all keypads. These keys
must be pressed and held for two seconds before they will
activate. This two second delay is designed to help prevent
accidental activation.
If the [F] / Key option is enabled, when the Fire keys are
pressed and held for two seconds, the panel will activate the
alarm output following the option programmed in section
[013]: [8] (see section 5.13
“Bell”
on page 23). The alarm out-
put will sound until a code is entered or until the bell cut-off
time expires. Communication of the signal to central station is
immediate.
If the [A] / Key is pressed and held for two seconds, the
panel will sound the keypad beeps three times to verify acti-
vation. The panel will beep the keypad ten times rapidly when
