Program Descriptions: 5.11 PGM Output Options
21
Code][499][Installer’s Code][499]. All keypads will be busy for
the duration of the PC-LINK connection. The status LEDs will
display the current system status on the keypad where the
PC-LINK was initiated. For more information on connecting the
PC-LINK, refer to your “PC-LINK Download Kit Instruction
Sheet”.
NOTE: When a zone status upload is performed through PC-
LINK, the information uploaded may not be accurate. For more
information, refer to your DLS-1 manual.
Downloading can also be performed through the LINKS1000
cellular communicator if the telephone line is disconnected. If
using the LINKS1000 with call back, you need to program the
LINKS1000 Preamble with the downloading telephone num-
ber in order for the panel to call the computer correctly.
NOTE:When uploading labels from LCD keypads, only labels
from the LCD keypad assigned to slot 8 will be uploaded.
Answering Machine/Double Call . . . . . . . . Section [401]: [1]
User Enable DLS Window . . . . . . . . . . . . . Section [401]: [2]
Call-Back . . . . . . . . . . . . . . . . . . . . . . . . . . Section [401]: [3]
User-initiated Call-up enabled/disabled. . . Section [401]: [4]
One/Six Hour User-enabled DLS Window . Section [702]: [7]
Downloading Computer’s Telephone Number Section [402]
Downloading Access Code . . . . . . . . . . . . . . . Section [403]
Panel Identification Code . . . . . . . . . . . . . . . . . Section [404]
Answering Machine Double Call Timer . . . . . . Section [405]
Number of Rings to Answer On . . . . . . . . . . . . Section [406]
LINKS1000 Preamble (Downloading) . . . . . . . Section [490]
Initiate Local Downloading (PC-LINK) . . . . . . . Section [499]
5.11 PGM Output Options
Program the programmable outputs PGM1 and PGM2 on the
main board by selecting one of the output options listed below
(exceptions noted).
Main Board PGM Outputs . . . . . . . . . . . . . . . . Section [009]
NOTE: PGM outputs cannot be completely disabled in
installer’s programming. To disable a PGM output completely,
you must remove all wiring from the output.
[01] Burglary and Fire Bell Output
The output will activate when the alarm output is active and
will deactivate when the alarm output is silenced. If the alarm
output is pulsing, the PGM output will pulse as well. This out-
put will follow the activation of the alarm output (pre-alert) for
delayed fire zones.
[02] For future use
[03] Sensor Reset ([*][7][2])
NOTE:This output will normally be active (switched to ground).
This option is used to reset power for latching smoke detec-
tors. The output will deactivate for five seconds when the
[*][7][2] command is entered. (See
“[*][7] Command Output
Functions”
on page 11.) The keypad buzzer will not sound for
the five second period.
Please refer to the Control Panel Wiring Diagram in this man-
ual for wiring instructions.
NOTE:Only ONE of options [03] Sensor Reset and [20] [*][7][2]
Command Output Option #2 may be programmed on the same
system.
[04] For future use
[05] Armed Status
When the system is armed, the PGM output will activate at the
beginning of the exit delay. The output deactivates when the
system is disarmed.
[06] Ready To Arm
The PGM will be active as long as the system is ready to arm
and all non-force armable zones on the system are restored.
Once an access code is entered to arm the system and the
exit delay begins, the PGM output is deactivated.
[07] Keypad Buzzer Follower Mode
The PGM will activate when any of the following events occur
and will remain active for as long as the keypad buzzer is
active:
• Door Chime • Entry Delay
• Auto-Arm Prealert • Audible Exit Delay
• 24 Hour Supervisory Buzzer Zone
[08] Courtesy Pulse
Upon arming, the PGM output will activate for the duration of
the exit delay plus an additional two minutes. Upon disarming,
the PGM output will activate for the duration of the entry delay
plus an additional two minutes.
[09] System Trouble Output
The PGM output will activate when any of the selected trouble
conditions are present. It will deactivate when all the selected
trouble conditions are cleared.
The PGM attributes for this option, programmed in Sections
[141] to [142], differ from the standard selection of attributes.
Program which trouble conditions will activate the output by
selecting some or all of the following attributes:
Attribute
[1]...........Service Required (battery, bell, general trouble,
general tamper, general supervisory)
[2]...........AC Failure
[3]...........Telephone Line Trouble
[4]...........Failure to Communicate
[5]...........Fire Trouble / Zone Fault
[6]...........Zone Tamper
[7]...........Zone Low Battery
[8]...........Loss of Clock
[10] System Event (Strobe Output)
The output activates when any of the selected system events
(alarms) occur on the system.
NOTE:This output will activate for silent and audible alarms or
medical conditions only. It will not activate during pre-alert or
delays.
If attribute [8] is turned ON, the output will activate for the
number of seconds programmed in the PGM output timer
(section [164]).
If attribute [8] is turned OFF, in the armed state, the output will
deactivate only once the system is disarmed. If an alarm acti-
vates this output in the disarmed state, the output will deacti-
vate if a user enters a valid access code while the Bell Cut-off
timer is counting down. The output will also deactivate if
someone arms the system after the Bell Cut-off has expired.
This output can be used to indicate that an alarm has
occurred before entering the premises.
The PGM attributes for this option, programmed in Sections
[141] to [142], differ from the standard selection of attributes.
Program which events will activate the output by selecting
some or all of the following attributes:
