DSC PC1565 - VERSION 2.3 User Manual

28
Section 6: Programming Worksheets
For the Record
Customer: _______________________________________________________________________________________________________
Address: ________________________________________________________________________________________________________
Telephone: ___________________________________________ Installation Date: ___________________________________________
Installer’s Code: __________________________________________________________________________________________________
Module Name Description Location
PC1565 Main Panel
I________________________________________________________________________________________________________________I
PC5132 Wireless Receiver I________________________________________________________________________________________________________________I
PC5400 Serial Printer Module I________________________________________________________________________________________________________________I
LINKS1000 Cellular Communicator I________________________________________________________________________________________________________________I
LINKS2X50 Long Range Radio I________________________________________________________________________________________________________________I
Keypads Keypad Type Location
Keypad 1
I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 2 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 3 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 4 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 5 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 6 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 7 I_____________________________________________I I________________________________________________________________________________________________________________I
Keypad 8 I_____________________________________________I I________________________________________________________________________________________________________________I

DSC PC1565 - VERSION 2.3 Specifications

General

Partitions	2
Event Buffer	128 events
Communicator	Built-in
PGM Outputs	2 (expandable)
Alarm System Type	Wired
Battery Backup	12VDC, 4Ah
Keypads Supported	8
Communication	Phone line
Power Supply	16.5VAC, 40VA
Operating Temperature	0°C to 49°C (32°F to 120°F)
