©1998 Digital Security Controls Ltd.
1645 Flint Road, Downsview, Ontario, Canada M3J 2J6
(416) 665-8460 • Fax (416) 665-7498 • 1-800-387-3630
www.dscgrp.com
Printed in Canada 29003286 R0
Changes for PC1565 v2.3
The PC1565 v2.3 software incorporates several new fea-
tures and changes. The most important additions are
listed below:
Number of Zones
System expandable to 8 zones using keypad zone
inputs and to 32 zones using the PC5132 wireless
expansion module. (See 1.2
“Additional Devices”
on
page 2.)
New Options & Features
• New access code attribute option determines
whether the bell squawks on arming/disarming. (See
“[*][5] Programming Access Codes”
on page 10.)
• New option allows bell squawk on Away arming only
(See 5.17
“Arming/Disarming Options”
on page 24.)
• Users can restart the exit delay once by pressing the
Away key.
New Downloading Software
Downloading software DLS-1 v6.7 must be used. Do not
attempt to perform downloading/uploading functions
with other software versions.
Default Changes
• Section [006] Installer’s code: 5555
• Section [160], Maximum Number of Dialing Attempts
- valid entries (000-015)
PC1565 Module Compatibility
Module Compatible? Comments
Classic Escort (VPM-1) No
Escort5580 No
PC-16 Out No
PC5204 No
PC5208 No
PC5108 No
PC5108L No
PC5132 v1.X Yes No support for Wireless Keys, Pendants or Handheld Keypads
PC5132 v2.X Yes No identified Wireless Keys support
PC5132 v3.X Yes
PC5506 No
PC55XX Yes No Keypad zone support
PC55XXZ Yes
PC5509 Yes
LCD5500 v1.X Yes No Keypad zone support; Some display messages not supported
LCD5500Z v2.X Yes
LCD600 No
LED615 No
SL-XX No
PC1500RK No
PC1555RKZ Yes
PC5908 No
PC5928 No
PC5400 Printer
Module v1.X to v2.1
Yes Some printing messages not supported
PC5400 Printer
Module v2.2
Yes
Links1000 Yes
Links2150 Yes
Links2450 Yes
