Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillage radioélectrique
subi, même sile brouillage est susceptible d'en compromettre le fonctionnement.
Wireless Notice
Thisequipmentcomplieswith FCC and IC radiation exposure limitsset forth foran uncontrolled environment. The antenna should be installed and oper-
ated with minimumdistance of 20 cm between the radiator and your body. Thistransmitter must not be co-located oroperating in conjunction with any
otherantenna ortransmitter.
Cet appareilestconforme aux limitesd'exposition auxrayonnementsde la IC pourun environnement non contrôlé. L'antenne doit être installé de façon
à garderune distance minimale de 20 centimètresentre la source de rayonnementset votre corps. L'émetteur ne doit pas être colocalisé nifonctionner
conjointement avecà autre antenne ou autre émetteur.
Antenna gain must be below / Gain de l'antenne doitêtre ci-dessous:
Frequency Band/Bande de fréquence TL2803GRE, TL2803GE, 3G2080RE, 3G2080E TL280LE, TL280LER, LE2080, LE2080R
GSM850 / FDD V 2.26 dBi -
PCS1900 / FDD II 2.41 dBi -
LTEB2 - 2.76 dBi
LTEB4 - 2.82 dBi
LTEB5 / B12 / B13 - 2.45 dBi
FCC Class B digital device notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there isno guarantee that interference will not occur in a particularinstallation. If this equipment does cause harmfulinterference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to tryto correct the interference by one or
more of the following measures:
-Reorient orrelocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different fromthat to which the receiverisconnected.
-Consult the dealeroran experienced radio/TVtechnician forhelp
CAN ICES-3 (B) / NMB-3 (B)
TL2803G(R)E -EU /3G2080(R)E- EU/TL280(R)E
LE2080(R)/TL280LE(R)
FCC ID:F5316TL2803GRE FCC ID:F5317TL280LER
IC: 160A-TL2803GRE IC:160A-TL280LER
Notes for EN50131-1:2006/A1:2009 Compliant installations:
ModelsTL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Eare an SPT Type Y- the module is mounted within CIEorPShousing and it receives powerfrom
the compatible CIE or Power Supplysource that are in compliance with EN50131-6:2008 Type Arequirements fora Grade 2, Class II application. This
producthasno replacement partsand software programmable optionsare accessible atlevel3 (installermode), section [851].
The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)E connects to compatible DSC alarmcontrolpanels using the DSC proprietary serial interface and
protocolPC-Link(converted also to RS-422). The module operates in pass-through mode and it doesacknowledge the alarmto the compatible control
panelafteran acknowledgement hasbeen received fromthe compatible alarmreceiver.
1. The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Emodule ismonitored bythe controlpaneland it isprogrammed via the programming menu
(* 8, section [851] in the controlpanel. The interface isconnected to the PC-Linkbus asshown in the diagramincluded in thismanual.
2. The HSPA3GCellularpath isimmune to conducted and radiated RFfieldswith levelsup to 10V/mastested perEN50130- 4 Standard.
3. The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Emodule conformswith radiated emissionslevels forClassBequipment asperstandards
EN61000-6-3/EN55022/CISPR22.
4. The TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Emodule uses AES128 encryption and heartbeat supervision forHSPA3G Cellular com-
munication pathsand it meetssecurity levelsS2 asper EN50136-2:2013. It also usesauthentication for each message exchanged with the
compatible receiverequipmentat ARC and it meetslevelI2 forinformation security.
5. The 3G2080(R)E-EU module hasonlyone communication path:
HSPA3GCellularcommunication path using 900/1800/2100MHzPublicCellularNetwork. The HSPA3GCellularcommunication path that can
be used in a standalone mode in conjunction with a DSC alarmsystem(compatible DSC alarmcontrolpanelmodels:HS2128/064/032/016).
The supported ATSconfiguration is: customcategoryC.
6. The TL280(R)Emodule hasonlyone communication path: Ethernet communication path using Internet. The communication path that can be
used in a standalone mode in conjunction with a DSC alarmsystem(compatible DSC alarmcontrolpanelmodels: HS2128/064/032/016). The
supported ATSconfiguration is: customcategoryC.
7. The TL2803G(R)E-EU module hastwo communication paths:HSPA3G Cellularcommunication path using 900/1800/2100MHzPublicCellular
Networkand Ethernetcommunication path using Internet. The communication pathscan be used in a standalone mode in conjunction with a
DSC alarmsystem(compatible DSC alarmcontrolpanelmodels: HS2128/064/032/016). The supported ATSconfiguration is: customcategory
C.
8. TL2803G(R)E-EU/3G2080(R)E-EU/TL280(R)Ehasbeen tested for compliance in conjunction with the following applicable standards:
EN50136-1:2012, EN50136- 2:2013, EN50131-10:2014, ATSconfiguration: C.
ForEN50131-1:2006/A1:2009 compliant installations, the following programming optionsshallbe set asdescribed.
Supervision Heartbeat: shallbe setto 180 seconds
NOTE: The compatible receiver at ARC location shall have supervision window programmed for 180 seconds. TL2803G(R)E-EU/3G2080 (R)E-
EU/TL280(R)E has been certified by TELEFICATION in accordance with EN50131-1:2006/A1:2009, EN50131-10:2014 requirements for Grade 2,
ClassII and EN50136-2:2013 Configuration:C
ATS Custom Category C Level
EN50136-1:2012 AnnexD Table D.1 D3
EN50136-1:2012 AnnexD Table D.2 M3
EN50136-1:2012 AnnexD Table D.3 T4
EN50136-1:2012 AnnexD Table D.4 A4 (Depending on cellularcarrierused)
EN50136-1:2012 AnnexD Table D.5
S2 (use AES-128 and authentication/sequential information in each
message transmitted to the SG receiver)
63
