EN50136-1:2012 AnnexD Table D.6 I2 (use AES-128 encryption)

EN50136-1:2012 Table 1

Use single communication path for models 3G2080 (R)E-EU (cellular

network), TL280 (R)E (Ethernet port) and two communication paths for

modelTL2803G(R)E-EU (cell/Ethernet).

EN50136-1:2012 Table 4 ATSfailure reported to ARC

EN50136-1:2012 Table 5

ATS failure reported to AS (DSC compatible control panel

HS2128/HS2064/HS2032/HS2016)

EN50136-1:2012 Table 6 There isno recording of availabilityfailure

EN50136-2:2013 Table 1 No logging function provided

EN50136-2:2013 Table 2 No memoryprovided forlogging function

EN50136-2:2013 Table 3 ATSfailure reported to ARC

SIMPLIFIED EU DECLARATION OF CONFORMITY

Hereby, Tyco Safety ProductsCanada Ltd declaresthat the radio equipment type isin compliance with Directive 2014/53/EU. The fulltext of the EU declar-

ationsof conformityforthe modelsmentioned below are available at the following internet addresses:

TL2803G(R)E-EU -http://dsc.com/pdf/1605003

3G2080(R)E-EU-http://dsc.com/pdf/1605004

Frequency Band Maximum Power

EGSM900 890.0MHz- 914.8MHz Class4 (2W)@ 900MHz,GSM

EGSM900 880.2MHz-889.8MHz Class1(1W)@ 1800MHz, GSM

DCS1800 1710.2MHz-1784.8MHz ClassE2 (0.5W)@ 900MHz,EDGE

WCDMA(Band VIII)882.4MHz-912.6MHz ClassE2 (0.4W) @ 1800MHz,EDGE

WCDMA2100 (Band I) 1922.4MHz-1977.6MHz Class3 (0.25W)@ 900/2100MHz,WCDMA

OnlymodelsTL2803GRE-EU, TL2803GE-EU, 3G2080RE-EU, 3G2080E-EU are CEcompliant.

European single point of contact:Tyco SafetyProducts,Voltaweg 20, 6101 XKEcht, Netherlands

UL/ULC Installation Requirements

NOTE: Forequipment used at the protected premisesand intended to facilitate IPcommunications (hubs, routers, NIDs, DigitalSubscriber Line (DSL), cable

modems), 24 hourbackup powerisrequired. Where such cannot be facilitated, a secondary(back-up)communication channelisrequired.

Domain Name Service (DNS) programming is not permitted in UL1610 listed systems.

Technical Specifications

The input voltage to the Communicatorcan be drawn fromthe UnderwritersLaboratories/UnderwritersLaboratoriesCanada (UL/ULC)listed controlpanel.

Notes for using Private, Corporate, and High Speed Data Networks:

Network access and domain accesspolicies shall be set to restrict unauthorized network access, and spoofing or Denial of Service (DoS) attacks. Select an

Internet Service Provider (ISP) that has redundant servers/systems, back-up power, routers with firewalls enabled, and methods to identify and protect

against DoSattacks(e.g.,via spoofing).

Notes for using Public Switched and Cellular Data Networks:

Communication channels shall be facilitated such that the communicator will restrict unauthorized access, which could otherwise compromise security. The

communicatorshallbe located in a secured area.

•For ULC Residential Fire and Burglary applicationsthe TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R) can be used asprimarycom-

munication channelvia either cellular or Ethernet or as a back-up in conjunction with the Digital AlarmCommunicator Transmitter (DACT). Test transmission

every24 hoursshallbe enabled on each channel.

• For ULC Commercial Fire and Burglary applications the TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R) can be used as a passive

communication module with the following securitylevels:

l P1 (each channelcellularorEthernet isindependent)

l P2 (cellularand Ethernetin back-up configuration, panelsection [851][005] toggle option [5] OFF).

l P3 (cellularand Ethernetin redundant configuration, panelsection [851][005] toggle option [5] ON).

The communicator can also be used as an active communication system with the security levels A1-A4 (each channel cellular or Ethernet independent or

together in a back-up/redundant configuration). For active line security systems AES128 bit encryption shall be enabled (at the monitoring station receiver)

and the supervision heartbeat rate shall be set as90 seconds(panelsection [851][004] = 005A/90). The supervision window at the SignalReceiver Center

(SRC)'sreceivershallbe programmed asmaximumof180 (00B4/180)seconds.

NOTE:ForULC commercialfire passive communication, encryption shallbe enabled,

•For UL Residential Fire and Burglary applications the TL2803G(R)E/3G2080R/TL280(R)E/LE2080(R)/TL280LE(R)can be used asthe primary com-

munication channelvia eithercellularorEthernet, orasa back-up in conjunction with the DACT (30 daytesttransmission isrequired on each channel).

• For UL Commercial Burglary applications the TL2803G(R)E/ 3G2080R / TL280(R)E / LE2080(R) / TL280LE(R) can be used as dualsignalling line

communication system(cellularand Ethernet channelsused in redundantconfiguration), standard line securityand asencrypted line security.

• The supervision heartbeat shall be enabled (panelsection [851][005] toggle option [1] (Ethernet) and/or toggle option [2] (cellular) shall be ON), toggle

option [3] (supervision type) shall be ON and the supervision heartbeat rate shall be selected as 135 (0087/135) seconds. Option [004] = 0087. The super-

vision window at the supervising station shall be maximum 200 (00C8/200) seconds. For encrypted line security systemsthe encryption AES128 bit shall be

enabled at the monitoring station receiver.

• For UL Commercial Burglary installations, the TL2803G(R)E/3G2080 (R)E/TL280 (R)E/LE2080 (R)/TL280LE(R) is listed as a primary (sole) com-

munication means (heartbeat must be enabled) or for supplementary (back-up) use in conjunction with a Plain Old Telephone Service (POTS) line dialer.

When the heartbeat transmission over the Ethernet orcellular network is enabled, using the TL2803G(R)E/3G2080(R)E/TL280(R)Ewith a compatible con-

trolunit listed forstandard/encrypted line security, it can provide line securityforthe alarmsystemover the primaryline.

• The TL2803G(R)E/3G2080(R)E/TL280(R)E/LE2080(R)/TL280LE(R) is also suitable to be used with a compatible control unit listed for dualline security

transmission when used in conjunction with a DACT or a Public Switched Data Network(PSDN) transmitter, where the PSDN provides the line securityand is
