5
I N S T A L L A T I O N
To review which modules the control panel is currently supervising:
1. Enter [✱][8][Installer’s Code]
2. Enter [903] to display all modules. On the
RF5501-433 keypad,
11
11
1 and
11
11
1
77
77
7 will scroll on
the keypad to indicate that the
RF5501-433 is present on the system.
11
11
1 designates
the keypad section, and
1717
1717
17 is used to show the receiver section is also supervised.
If using an LCD5501Z keypad, scroll until the module name appears on the display.
3. To exit press [#].
If both modules do not show on the keypad, one of the following conditions may be present:If both modules do not show on the keypad, one of the following conditions may be present:
If both modules do not show on the keypad, one of the following conditions may be present:If both modules do not show on the keypad, one of the following conditions may be present:
If both modules do not show on the keypad, one of the following conditions may be present:
• the keypad is not connected properly to the Keybus
• there is a problem with the Keybus wiring run
• the keypad does not have enough power
1.6 Downloading
This product has an integrated RF5501-433 v5.0 receiver. When downloading to this
keypad, please select the PC5132-433 v5.0 file. DLS2002 and greater must be used in
order to have the capability of downloading to this keypad.
1.7 Compatible Wireless Devices
Please refer to the Instruction sheets of the following devices for more information.
The RF5501-433 v5.0 can receive signals from the following devices:
• WLS904L-433 Motion Detector • WLS912L-433 Glass Break Detector
• WLS904PL-433 Pet Immune PIR • WLS914-433 Pet Immune PIR
• WLS906-433 Smoke Detector • WLS909-433 Wireless Key
• WLS907-433 Universal Transmitter • WLS919-433 Wireless Key
• WLS907T-433 Low Temperature Sensor • WLS925L-433 Mini Door/Window Contact
1.8 Batteries
The wireless devices are designed to use only specific brands and types of batteries.
Please see the appropriate instruction sheet for detailed information on the battery
brands and types.
NOTE: Do not use brands of batteries other than those specified. Using any other
brand may affect system operation.
