6
2.1 Programming the Keypad
There are several programming options available for the RF5501-433 keypad. These
are described below. Record all your programming choices in the programming
worksheets included in this manual.
Programming the RF5501-433 is similar to programming the rest of the system. When
you are in the RF5501-433 programming sections, the keypad will display which options
are turned on along the top of the display. To turn an option on or off, press the number
corresponding to the option on the number pad. The numbers of the options that are
currently turned ON will be displayed.
For example, if options 1 and 2 are on, the display will look like this:
For information on programming the rest of your security system, please refer to your
system’s
Installation Manual
.
2.2 Function Key Options
The function keys are programmed in sections [1] to [5]. By default, the 5 function keys
on the keypad are programmed as Stay Arm (03), Away Arm (04), Chime (06), Sensor
Reset (14) and Quick Exit (16). You can change the function of each key on every
keypad. Please see your system’s
Installation Manual
for instructions on programming
the keys, and a complete list of all the function key options available for your system.
2.3 Clock Options
The RF5501-433 will display the current time after 30 seconds of no key presses. To
set the correct time and date for the system, please refer to your system’s
Instruction
Manual
. You can change how the keypad displays the time with the following
options. To change the clock options:
1. Enter [*][8][Installer Code]
2. Enter [000] to go to keypad programming
3. Enter section [6] to go to clock options.
4. To turn any of the options on or off, press [1], [2], or [3]:
NOTE: If the Time does not display on keypad option is selected, make sure that the
Keypad displays time when zones are open option is also selected.
[1] ON = Time displays on keypad
OFF = Time does not display on keypad
[2] ON = Clock display is in AM/PM format
(e.g. 08:00 AM)
OFF = Clock display is in 24-hour format (e.g. 20:00)
[3] ON = Keypad does not display time when zones are open
OFF = Keypad displays time when zones are open
5. When you are finished programming the clock options,
press [#] to exit.
NOTE: On a PC5020 v3.2 and higher, if a Loss of Clock trouble
is present on the system, the display will be as shown:
Keypad Programming
S E C T I O N 2
:
