Connecting the DStv Switch (5-1) to one
DStv Explora and one to four Single View Decoders
• Once the switch has been connected to the satellite dish,
use the supplied cable and connect output A or B on the
switch to the input labelled UNICABLE™ IN on the back of
your DStv Explora.
• Then connect the outputs labelled 1 to 4 on the switch to the
satellite inputs on the back of the Single View Decoder(s).
Use any
one of the
outputs.
H/L V/L H/H V/H
1 2 3 4
A
B
Single View Decoder(s)
DStv Explora
