DStv 5 - 3 Cable Quad LNB Connection (E36 B Angola and Mozambique only); Quattro LNB Connection

3 Cable Quad LNB Connection
(E36B Angola and Mozambique only)
Quad LNB
Any LNB cable can
connect to any of
these 3 inputs
H/L V/L H/H V/H
DStv Switch (5-1)
Quattro LNB Connection
Quattro LNB
Use quattro
LNB output
labels to match
DStv Switch (5-1)
input labels.
H/L V/L H/H V/H
H/L
V/L
H/H
V/H
DStv Switch (5-1)
5
DStv Switch - User Guide
