DTS 03.MS014.EBLFP User Manual

32
19- DMX PROTOCOL
33 CHANNELS MODE
1 PAN msb
2 PAN lsb
3 TILT msb
4 TILT lsb
5 SPEED MOVEMENT
6 FPR MODE
7 DIMMER
8 SHUTTER
9 COLOUR
10 COLOUR MODE
11 CYAN
12 MAGENTA
13 YELLOW
14 CTO
15 SPEED CMY
16 MACRO CMY
17 GOBO
18 GOBO MODE
19 GOBO ROTATION / INDEX
20 GOBO INDEX FINE
21 GOBO SHAKE
22 FIXED GOBO
23 FIXED GOBO SHAKE
24 IRIS
25 IRIS MACROS
26 ANIMATION
27 FROST
28 PRISM
29 PRISM / ANIMATION ROTATION
30 FOCUS
31 FOCUS FINE
32 ZOOM
33 RESET + LAMP
DMX CHANNEL
1
Parameter: PAN msb
DMX CHANNEL
2
Parameter: PAN lsb
DMX CHANNEL
3
Parameter: TILT msb
DMX CHANNEL
4
Parameter: TILT lsb
DMX CHANNEL
5
Parameter: SPEED MOVEMENT
DMX value
Function
000-010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to dmx signal (fast to slow)
248-255
Silent movement
